LLVT-SERIES

LLVT - LED Linear Vapor Lights

Technical Specs

:: Housing: Polycarbonate
:: Lens: Opal PC (for more info, see the spec sheets)
:: With steel clamps
:: Input Voltage: 120V~277V AC
:: Dimmable (0~10V dimming)
:: IP65
:: Ideal for offices, retail stores, showrooms and residential applications. Especially suited for areas where accessing the fixture is challenging

Applications

:: Ideal for offices, retail stores, showrooms, and residential applications. Uniquely suited for areas where accessing the fixture is challenging.
:: Suitable for restaurants, bakeries, food facilities, gyms, pool areas, and any application where NSF certified fixtures or high-end architectural designer grade fixtures are required.
:: NSF/ANSI 2:2015 Food Equipment: Splash Zone: Equipment surfaces that are subject to splash and food spillage during operation of the equipment other than those in a direct contact food-zone.

Variations
Q & A (0)

Product Name	Lumens	Color Temp	Watts	Dimensions	Description	Factory-Installed Options
LLVT-2FT-25W-40K-D SPEC INST	3125LM	4000K	25W	27"(L) x 6-3/4""(W) x 3-3/4""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM1INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-2FT-25W-50K-D SPEC INST	3125LM	5000K	25W	27"(L) x 6-3/4""(W) x 3-3/4""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-SEN-2MDR-36 OPT-HBC-277TL-WH OPT-EM-CM1INT WEC-3RC
LLVT-4FT-40W-40K-D SPEC INST	5000LM	4000K	40W	27"(L) x 6-3/4""(W) x 3-3/4""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-EM-CM1INT OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-40W-50K-D SPEC INST	5000LM	5000K	40W	49-3/4"(L) x 6-3/4""(W) x 3-3/4""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-75W-40K-D SPEC INST	9375LM	4000K	75W	49-3/4"(L) x 6-3/4""(W) x 3-3/4""(H)"		OPT-HBC-125TL-WH OPT-HBC-125SB-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-75W-50K-D SPEC INST	9375LM	5000K	75W	49-3/4"(L) x 6-3/4""(W) x 3-3/4""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-100W-40K-D SPEC INST	13500LM	4000K	100W	52.4"(L) x 14.6""(W) x 4.7""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-100W-50K-D SPEC INST	13500LM	5000K	100W	52.4"(L) x 14.6""(W) x 4.7""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-150W-40K-D SPEC INST	20250LM	4000K	150W	52.4"(L) x 14.6""(W) x 4.7""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-150W-50K-D SPEC INST	20250LM	5000K	150W	52.4"(L) x 14.6""(W) x 4.7""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-SEN-2MDR-36 WEC-3RC
LLVT2-4FT-40W-50K-D SPEC INST	4800LM	5000K	40W	4-1/2" Wide"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT2-4FT-40W-40K-D SPEC INST	4800LM	4000K	40W	4-1/2" Wide"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-8FT-68W-40K-D SPEC INST	7300LM	4000K	68W	8'x6-3/4""		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-8FT-68W-50K-D SPEC INST	7300LM	5000K	68W	8'x6-3/4""		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM2INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-8FT-65W-40K-D INST SPEC	8450LM	4000K	65W	8'x6-3/4""		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-8FT-65W-50K-D SPEC INST	8450LM	5000K	65W	8'x6-3/4""		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-SEN-2MDR-36 OPT-HBC-277TL-WH WEC-3RC OPT-EM-CM2INT
LLVT-8FT-100W-40K-D SPEC INST	8450LM	4000K	100W	8'x6-3/4""		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-8FT-100W-50K-D SPEC INST	13000LM	5000K	100W	8'x6-3/4""		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT2-4FT-36W-35K-D SPEC INST	4680LM	3500K	36W	4-1/2" Wide"		OPT-EM-CM1INT OPT-SEN-2MDR-36 OPT-HBC-277TL-WH OPT-HBC-125SB-WH OPT-HBC-125SB-WH OPT-HBC-125TL-WH
LLVT2-4FT-36W-40K-D SPEC INST	4680LM	4000K	36W	4-1/2" Wide"		OPT-EM-CM1INT OPT-SEN-2MDR-36 OPT-HBC-277TL-WH OPT-HBC-125SB-WH OPT-HBC-125TL-WH WEC-3RC
LLVT2-4FT-36W-50K-D SPEC INST	4680LM	5000K	36W	4-1/2" Wide"		OPT-EM-CM1INT OPT-SEN-2MDR-36 OPT-HBC-277TL-WH OPT-HBC-125SB-WH OPT-HBC-125TL-WH WEC-3RC
LLVT-4FT-75W-MCT-D SPEC INST	9375LM	3500K/4000K/5000K	75W	6-3/4" Wide"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-4FT-40W-MCT-D SPEC INST	5230LM	3500K/4000K/5000K	40W	6-3/4" Wide"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM1INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-2FT-25W-MCT-D SPEC INST	2984LM/3125LM/3304LM	3500K/4000K/5000K	25W	27"(L) x 6-3/4""(W) x 3-3/4""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM1INT
LLVT2-4FT-36W-MCT-D SPEC INST	4580LM/ 4700LM/ 4600LM	3500K/4000K/5000K	36W	4-1/2" Wide"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-EM-CM1INT OPT-SEN-2MDR-36 WEC-3RC
LLVT2-4FT-46W-MCT-D SPEC INST	6100LM/ 6350LM/ 6200LM	3500K/4000K/5000K	46W	4-1/2" Wide"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-EM-CM1INT OPT-SEN-2MDR-36 WEC-3RC
LLVT2-4FT-65W-MCT-D SPEC INST	8450LM	3500K/4000K/5000K	65W	4-1/2" Wide"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-4FT-100W-MCT-D SPEC INST	13500LM	3500K/4000K/5000K	100W	52.4"(L) x 14.6""(W) x 4.7""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-4FT-150W-MCT-D SPEC INST	20250LM	3500K/4000K/5000K	150W	52.4"(L) x 14.6""(W) x 4.7""(H)"		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-4FT-RL INST SPEC					Replacement Lens for LLVT-4FT-40W&75W
LLVT-4FT-100W-MCTP-D SPEC INST	13500LM Max	3500K/4000K/5000K	50W/80W/100W	52.4”(L) x 14 3/5”(W) x 4 3/4”(H)		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-2FT-RL INST SPEC					Replacement Lens for LLVT-2FT
LLVT-4FT-150W-MCTP-D SPEC INST	19500LM Max.	3500K/4000K/5000K	80W/110W/150W	52 2/5”(L) x 14 3/5”(W) x 4 3/4”(H)		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-4FT-RL2C INST SPEC					Optional replacement Clear Lens for LLVT-100W&150W
LLVT-4FT-40W-MCTP-D SPEC INST	5224LM/3900LM/5500LM	2600K/4000K/5000K	20W/30W/40W	50-1/4” (L) x 6-3/4” (W) x 3-3/4” (H)		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-EM-CM1INT OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC
LLVT-4FT-RL2T SPEC INST					Optional replacement Frosted Lens for LLVT-100W&150W
LLVT-4FT-75W-MCTP-D SPEC INST	9750LM	3500K/4000K/5000K	40W/60W/75W	50-1/4” (L) x 6-3/4” (W) x 3-3/4” (H)		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-CM2INT
LLVT-2FT-25W-MCTP-D SPEC INST	1950LM/2600LM/3250LM	3500K/4000K/5000K	15W/20W/25W	27”(L) x 6-3/4”(W) x 3-3/4”(H)		OPT-HBC-125SB-WH OPT-HBC-125TL-WH OPT-HBC-277TL-WH OPT-SEN-2MDR-36 WEC-3RC OPT-EM-LLVT-25-46
LLVT-4FT-200W-MCTP-D SPEC INST	26000LM Max.	3500K/4000K/5000K	200W	52 2/5”(L) x 14 3/5”(W) x 4 3/4”(H)
