FINAL PRODUCTION
STL3-SERIES-120V STL3 - LED Street/Roadway Lights with NEMA Twist-Lock Photocell Socket (120V)
Technical Specs
- :: Die-cast Aluminum with Powder Coat Finish (Light Grey)
- :: With NEMA twist-lock Photocell Socket (Shorting Cap Included)
- :: With 1-31/32-inch iameter pole entry with adapter bracket inside smaller pole diameter
- :: Driver location is isolated compartment for improved thermal management
- :: Code Type: 40-inch SJTW 18/3 AWG Cable
- :: Lens: Optical Type III Len, High Light Transmittance PC, Anti-UV & Flame Resistant
- :: Lumens: 3900LM/6750LM/10800LM/13500LM/21000LM/27000LM
- :: Wattage: 30W/50W/80W/100W/150W/200W
- :: Voltage: 120-277V 60Hz AC
- :: Efficacy: 130LPW/135LPW/140LPW
- :: Power Factor: >0.95
- :: Maximum Ambient Temperature: 104°F
- :: Color Rendering Index: CRI ≥ 70
- :: Color Temp: 3000K/5000K
- :: Lifespan: 50,000 hours
- :: 7-year warranty
- :: IP Rating: IP65, Wet Locations
Applications
- :: Ideal for general site lighting, street, roadway, alleys, loading docks, doorways, pathways and parking areas.
- Variations
- Q & A (0)
| Product Name | Lumens | Color Temp | Watts | Features | |
|---|---|---|---|---|---|
 STL3-30W-30K  SPEC BRCH INST  IES | 3900LM | 3000K | 30W |      | |
STL3-30W-50K SPEC BRCH INST IES | 3900LM | 5000K | 30W | | |
STL3-50W-30K SPEC INST BRCH IES | 6750LM | 3000K | 50W | | |
STL3-50W-50K SPEC INST BRCH IES | 6750LM | 5000K | 50W | | |
 STL3-50W-30K-L SPEC INST BRCH IES | 6750LM | 3000K | 50W | | |
STL3-50W-50K-L SPEC INST BRCH IES | 6750LM | 5000K | 50W | | |
STL3-80W-30K SPEC BRCH INST IES | 10800LM | 3000K | 80W | | |
STL3-80W-50K SPEC BRCH INST IES | 10800LM | 5000K | 80W | | |
STL3-100W-30K SPEC BRCH INST IES | 13500LM | 3000K | 100W | | |
STL3-100W-50K SPEC BRCH INST IES | 13500LM | 5000K | 100W | | |
 STL3-150W-30K SPEC BRCH INST IES | 21000LM | 3000K | 150W | | |
STL3-150W-50K SPEC BRCH INST IES | 21000LM | 5000K | 150W | | |
STL3-200W-50K SPEC BRCH INST IES | 27000LM | 5000K | 200W | |
