 | W2B75-3 | - :: Dimensions: width 4-9/16", height 4-½", depth 2"
- :: Material: die-cast aluminum with powder-coated finish
- :: Outlet holes: available with 3, 4, 5, 6, 7, or 9 outlet holes
- :: Hole size: available in ½" or ¾" threaded outlet holes
- :: Color: grayPRODUCT FEATURES
- ::: Reinforced connector outlets
- :: Scratch resistant powder-coated finish
- :: Suitable for wet locations - NEMA 3R rated
- :: Connector outlets accept threaded fittings & conduit
- :: Retail-ready packaging (shrink-wrapped with barcode)
- :: Closure plugs, mounting lugs and ground screws included
- :: "X" denotes boxes with side outlets
| | |
 | W1B75-3 | - :: Dimensions: width 2-¾", height 4-½", depth 2"
- :: Material: die-cast aluminum with powder-coated fnish
- :: Available with 3, 4, or 5 reinforced threaded outlet holes
- :: Outlet hole sizes: available in ½" or ¾" threaded outlet holes
- :: Color: gray (select items available in white*)PRODUCT FEATURES
- ::: Scratch resistant powder-coated fnish
- :: Suitable for wet locations - NEMA 3R rated
- :: Reinforced connector outlets that accept threadedfttings & conduits
- :: Retail-ready packaging (shrink-wrapped with barcode)
- :: Closure plugs, mounting lugs and ground screws included*
- :: "X" denotes boxes with side outlets
| | |
| W1DB50-3 | - :: Dimensions: width 2-¾", height 4-½", depth 2-5/8"
- :: Material: die-cast aluminum with powder-coated finish
- :: Available with 3, 4, or 5 reinforced threaded outlet holes
- :: Outlet hole sizes: available in ½", ¾" or 1" threaded outlet holes
- :: Color: grayPRODUCT FEATURES
- ::: Reinforced connector outlets
- :: Scratch resistant powder-coated finish
- :: Suitable for wet locations - NEMA 3R rated
- :: Reinforced connector outlets that accept threadedfittings & conduits
- :: Retail-ready packaging (shrink-wrapped with barcode)
- :: Closure plugs, mounting lugs and ground screws included
- :: "X" denotes boxes with side outlets
| | |
| W1B50-3 | - :: Dimensions: width 2-¾", height 4-½", depth 2"
- :: Material: die-cast aluminum with powder-coated fnish
- :: Available with 3, 4, or 5 reinforced threaded outlet holes
- :: Outlet hole sizes: available in ½" or ¾" threaded outlet holes
- :: Color: gray (select items available in white*)PRODUCT FEATURES
- ::: Scratch resistant powder-coated fnish
- :: Suitable for wet locations - NEMA 3R rated
- :: Reinforced connector outlets that accept threadedfttings & conduits
- :: Retail-ready packaging (shrink-wrapped with barcode)
- :: Closure plugs, mounting lugs and ground screws included*
- :: "X" denotes boxes with side outlets
| | |
 | W1DB100-3 | - :: Dimensions: width 2-¾", height 4-½", depth 2-5/8"
- :: Material: die-cast aluminum with powder-coated finish
- :: Available with 3, 4, or 5 reinforced threaded outlet holes
- :: Outlet hole sizes: available in ½", ¾" or 1" threaded outlet holes
- :: Color: grayPRODUCT FEATURES
- ::: Reinforced connector outlets
- :: Scratch resistant powder-coated finish
- :: Suitable for wet locations - NEMA 3R rated
- :: Reinforced connector outlets that accept threadedfittings & conduits
- :: Retail-ready packaging (shrink-wrapped with barcode)
- :: Closure plugs, mounting lugs and ground screws included
- :: "X" denotes boxes with side outlets
| | |
 | WG-3 | - :: High-impact resistant chrome-plated steel
- :: Mounting hardware provided for easy installation
| | |
| W1DB75-3 | - :: Dimensions: width 2-¾", height 4-½", depth 2-5/8"
- :: Material: die-cast aluminum with powder-coated finish
- :: Available with 3, 4, or 5 reinforced threaded outlet holes
- :: Outlet hole sizes: available in ½", ¾" or 1" threaded outlet holes
- :: Color: grayPRODUCT FEATURES
- ::: Reinforced connector outlets
- :: Scratch resistant powder-coated finish
- :: Suitable for wet locations - NEMA 3R rated
- :: Reinforced connector outlets that accept threadedfittings & conduits
- :: Retail-ready packaging (shrink-wrapped with barcode)
- :: Closure plugs, mounting lugs and ground screws included
- :: "X" denotes boxes with side outlets
| | |
| W2B50-3 | - :: Dimensions: width 4-9/16", height 4-½", depth 2"
- :: Material: die-cast aluminum with powder-coated finish
- :: Outlet holes: available with 3, 4, 5, 6, 7, or 9 outlet holes
- :: Hole size: available in ½" or ¾" threaded outlet holes
- :: Color: grayPRODUCT FEATURES
- ::: Reinforced connector outlets
- :: Scratch resistant powder-coated finish
- :: Suitable for wet locations - NEMA 3R rated
- :: Connector outlets accept threaded fittings & conduit
- :: Retail-ready packaging (shrink-wrapped with barcode)
- :: Closure plugs, mounting lugs and ground screws included
- :: "X" denotes boxes with side outlets
| | |
 | HSL-3-30K | - :: Cast Aluminium Fixture, Stainless Steel Bracket, Aluminium Front Trim with Dark Gray Finish (Paintable)
- :: Built-In Glass Magnifying Lens
- :: Lumens: 30LM
- :: Wattage: 1W
- :: Voltage: 12V AC
- :: Light Source: LED COB Technology
- :: Beam Angle: 36°
- :: IP Rating: IP67, Wet Locations
| |  BRCH |
 | SCX-2FT-20W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 20W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: LPW: 110
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 2200LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT(Selectable with Switch Inside the Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX-2FT-20W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 20W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 2197LM/2316LM/2348LM/2390LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable with Switch Inside the Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | POL-D1-120-3PC-BK | - :: 120In Decorative Pole D1 Series, 3Pc, 2.36In Tenon, Black
| | SPEC |
 | HL2R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | SCX-3FT-30W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 30W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens:3300LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX-4FT-40W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 40W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole onthe End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 4400LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | ULR-IN-PIDR-72W | - :: Input voltage: 100~240VAC, 50/60Hz
- :: AC Input Current: Max 1A
- :: Output power: 72W
- :: Output DC Voltage: 24VDC
- :: Min Load: 3A
- :: Rated Load: 3A
- :: Line Regulation: ± 5%
- :: Load Regulation: ± 5%
- :: Efficiency: 83% Min
- :: Turn on delay time: 2Sec Max. at 115VAC & Max Load
- :: Rise time: 40mS Min. at 115VAC & Max Load
- :: Hold up time: 5mS Min. at 115VAC & Max Load
- :: Male 24V connector included
- :: Operating Temperature: 32°F to 104°F
- :: Protection Function: Short Circuit Test, Over current protection, Over Voltage Protection
- :: Relative Humidity: 5% to 90% RH, 72Hrs, Full Load , Normal operating.
- :: Ripple and Noise: 150mV p-p
| | SPEC |
 | DLST6-MCT5-IP65 | - :: Voltage: 120V AC
- :: Power Factor: >0.90
- :: Wattage: 10W
- :: Efficacy: 100 LPW
- :: White Finish
- :: Polycarbonate Housing
- :: Fits on 4” Octagonal (4O) or 3” Octagonal (3O) Electrical Boxes
- :: Recessed Mounting Springs & Kit included
- :: Maximum Ambient Temperature: -4°F to 104°F
- :: IP65, Suitable for wet location
- :: 5-Year Warranty
- :: Lens: White Translucent Acrylic
- :: MCT: The Switch is On The LED Board Under The Lens
- :: LED: Unique DOB (Driver On Board) LED BoardEnclosed in Clear PC Cover for Better Damp LocationPerformance
- :: Dimming: TRIAC Dimming (Using Standard TRIAC LED Dimmers)
- :: Total Lumens: 1000LM
- :: Color Temperatures: 2700K/3000K/3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Rated life: 50,000 hrs
- :: Beam Angle: 120°
| | SPEC |
 | SCX4-IP66-SUR-8FT-80-160W-MCTP | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W/120W/160W
- :: Power Factor: >0.95
- :: LPW: 110
- :: Total Harmonic Distortion: ≤ 19 %
- :: 6FT. Lead 18/5 AWG SJTW on One Side
- :: 1FT. Lead 18/5 AWG SJTW on The Other Side For DaisyChaining. The Cord Can be Tucked in If Not Needed,Weatherproof 1/2” NPT Plug Provided to Cover The Hub.
- :: All Wires Are Capped
- :: Two Steel Compression Connectors Provided.
- :: Surface Mounting Brackets with Screws & Anchors Included
- :: Low Profile Modern Design
- :: Aluminum Housing With Sandy White Finish
- :: Mounting Options: Surface
- :: IP Rating: IP66 Wet Location Only
- :: Operating Temperature: -22°F to +104°F
- :: 5-Year Warranty
- :: MCTP: Multi Color Temperature and Power (Select-able Switch On Fixture)
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 17600LM Max.
- :: Color Temperatures: 3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 105°(H) x 103.7°(V)
| | |
 | SCX4-IP66-SUS-8FT-80-160W-MCTP | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W/120W/160W
- :: Power Factor: >0.95
- :: LPW: 110
- :: Total Harmonic Distortion: ≤ 19 %
- :: Wall Mounting Kit Included
- :: Suspended With Optional Stainless Steel Down Rod Kitsor Heavy-Duty Aircraft Cables
- :: Waterproof Male & Female Connectors Pre-Installed OnThe Top Near The Two Ends
- :: Low Profile Modern Design
- :: Aluminum Housing With Sandy White Finish
- :: Mounting Options: Suspended, Wall
- :: IP Rating: IP66 Wet Location Only
- :: Operating Temperature: -22°F to +104°F
- :: 5-Year Warranty
- :: MCT: Multi Color Temperature and Power (SelectableSwitch Fixture)
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 17600LM Max.
- :: Color Temperatures: 3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 105°(H) x 103.7°(V)
| | |
 | SCX-3FT-30W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 30W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole onthe End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 3300LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX-4FT-40W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 40W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: LPW: 110
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 4400LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
| POL-D1-144-3PC-BK | - :: 144In Decorative Pole D1 Series, 3Pc, 2.36In Tenon, Black
| | SPEC |
| SCX-6FT-60W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 60W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 6600LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX-6FT-60W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 60W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 6600LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | POL-D1-144-3PC-BR | - :: 144In Decorative Pole D1 Series, 3Pc, 2.36In Tenon, Bronze
| | SPEC |
FT%20Resized.jpg%3Falt%3Dmedia&w=3840&q=75&dpl=dpl_GaNPVVxr7qVWdrwq74iqjv8m7W2t) | SCX4-IP66-ACPT-10FT | - :: SCX4-IP66 10Ft Ac Pigtail With Female Wet Loc. Connector
| | SPEC |
 | SCX-8FT-80W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: LPW: 110
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 8800LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX-IC-MCT4 | - :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
- :: Ambient Temperature: -13°F~104°F
- :: Dimmable: 0~10V dimmable
- :: CRI:>80
- :: Power Factor:>0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | |
| SCX-8FT-80W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 8800LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: Up Light Option Available
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
| SCX-IC-MCT4 | - :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
- :: Ambient Temperature: -13°F~104°F
- :: Dimmable: 0~10V dimmable
- :: CRI:>80
- :: Power Factor:>0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | |
 | HL4DW-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outswith strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | ULR-IN-98F-HO-35K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8” on center, 19 per foot,0.23wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 310~350LM per ft.
- :: Color temperature: 3500K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
 | ULR-IN-98F-XHO-35K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 8.8W per ft.
- :: Max Run: 11ft.
- :: Efficacy: 70~79LM/W per ft.
- :: Cutting increment: Every 2 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 1/3” on center, 37 per foot,0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 620~700LM per ft.
- :: Color temperature: 3500K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | BRCH SPEC |
 | HL6R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | SCX4-IC-MCT4 | - :: Low Profile Modern Design
- :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Lens Snaps into Housing
- :: Lens Type: Polished Aluminum Louver Lens
- :: Mounting Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Dimmable: 0~10V Dimming
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: Up Light Option Available
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | SPEC  IES |
 | HL6-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation lagging
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-BoxvUL listed for damp location.
- :: UL listed for Air Tight construction
- :: Meet Title24 requirement
- :: ETLus
| | SPEC INST |
 | HL6S-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation lagging
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
| SCX-IC-MCT4 | - :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
| SCX-IC-30K | - :: Lumens: 629LM
- :: Color Temperatures: 3000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
| SCX-IC-35K | - :: Lumens: 726LM
- :: Color Temperatures: 3500K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
| SCX-IC-40K | - :: Lumens: 787LM
- :: Color Temperatures: 4000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
| SCX-IC-50K | - :: Lumens: 854LM
- :: Color Temperatures: 5000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
 | ELB-CW-27W-MV-IP66 | | | |
 RESIZED.jpg?alt=media)
 1 RESIZED.jpg?alt=media)
 1 RESIZED.jpg?alt=media)
.jpeg?alt=media)
 (Fixed).jpg?alt=media)
 (Fixed).jpg?alt=media)
 (Fixed).jpg?alt=media)
 (Fixed).jpg?alt=media)
.jpg?alt=media)
.jpg?alt=media)
.jpg?alt=media)
.jpg?alt=media)
