RSL-SSL-SERIES

LED Ultra Slim Recessed Lights

Technical Specs

:: Die-cast aluminum with white powder coat finish
:: Pot light housing is not required even for insulated ceilings
:: Optics: White translucent acrylic lens
:: Lens: 0.125" white translucent acrylic
:: Type IC rated - Approved for direct contact with insulation
:: CRI: >80
:: Working voltage: 120V AC
:: Beam Spread: 100-110°
:: Dimmable
:: LED: Seoul DOB (Driver On Board) Technology
:: Power factor: 90% +
:: Air-tight and damp location approved
:: Maximum Ambient Temperature: -40°F~104°F
:: 50000 Hours, 5-year warranty
:: ETL-listed
:: Energy Star-rated

Applications

:: LED recessed trims have been designed to be a flexible lighting solution for new construction applications, Ideal for closets, storage areas, attics, corridors, or general lighting solutions for residential and commercial applications

Variations
Q & A (2)

Product Name	Diameter	Lumens	Color Temp	Watts	Description	Factory-Installed Options
RSL4-27K BRCH SPEC IES	4"	540LM	2700K	9W
RSL4-30K BRCH SPEC IES	4"	540LM	3000K	9W
RSL4-40K BRCH SPEC IES	4"	540LM	4000K	9W
RSL4-50K BRCH SPEC IES	4"	540LM	5000K	9W
RSL6-27K BRCH SPEC IES	6"	900LM	2700K	15W
RSL6-30K BRCH SPEC IES	6"	900LM	3000K	15W
RSL6-40K BRCH SPEC IES	6"	900LM	4000K	15W
RSL6-50K BRCH SPEC IES SPD	6"	900LM	5000K	15W
RSL4-RI BRCH SPEC					4" round Rough-in
RSL6-RI BRCH SPEC					6" round Rough-in Plate
SSL4-27K BRCH SPEC IES	4"	540LM	2700K	9W
SSL4-30K BRCH SPEC IES	4"	540LM	2700K	9W
SSL4-40K BRCH SPEC IES	4"	540LM	4000K	9W
SSL4-50K BRCH SPEC IES	4"	540LM	5000K	9W
SSL6-27K BRCH SPEC IES	6"	900LM	2700K	15W
SSL6-30K BRCH SPEC IES	6"	900LM	2700K	15W
SSL6-40K BRCH SPEC IES	6"	900LM	3000K	15W
SSL6-50K BRCH SPEC IES	6"	900LM	5000K	15W
RSL4-30K-BN SPEC BRCH IES	4"	540LM	3000K	9W
RSL4-30K-ORB SPEC BRCH IES	4"	540LM	3000K	9W
RSL6-30K-BN SPEC BRCH IES	6"	900LM	3000K	15W
RSL6-30K-ORB SPEC BRCH IES	6"	900LM	3000K	15W
RSL3-27K SPEC BRCH IES	3"	630LM	2700K	9W
RSL3-30K SPEC BRCH IES	3"	630LM	3000K	9W
RSL3-30K-BN SPEC BRCH IES	3"	630LM	3000K	9W
RSL3-30K-ORB SPEC BRCH IES	3"	630LM	3000K	9W
RSL3-40K SPEC BRCH IES	3"	630LM	4000K	9W
RSL3-50K SPEC BRCH IES	3"	630LM	5000K	9W
RSL8-30K SPEC BRCH IES	8"	12600LM	3000K	18W
RSL8-40K SPEC BRCH IES	8"	12600LM	4000K	18W
RSL8-50K SPEC BRCH IES	8"	12600LM	5000K	18W
RSL12-30K IES SPEC	12"	1800LM	3000K	24W
RSL12-40K IES SPEC	12"	1800LM	4000K	24W
RSL12-50K IES SPEC	12"	1800LM	5000K	24W
RSL3-RI SPEC					3" round Rough-in
RSL4-RI-13 SPEC					4" round Rough-in
RSL6-RI-13 SPEC					6" round Rough-in
SSL12-30K IES SPEC	12""	1800LM	3000K	24W
SSL12-40K IES SPEC	12""	1800LM	4000K	24W
SSL12-50K IES SPEC	12""	1800LM	5000K	24W
RSL3-MCT IES SPEC BRCH	3"	420LM	3000K/4000K/5000K	6W
RSL4-MCT IES SPEC BRCH	4"	675-720LM	3000K/4000K/5000K	9W
RSL6-MCT SPEC IES BRCH	6"	1125-1200LM	3000K/4000K/5000K	15W
RSL12-MCT SPEC IES BRCH	12"	2100LM	3000K/4000K/5000K	28W
SSL6-MCT IES SPEC BRCH	6"	1125-1200LM	3000K/4000K/5000K	15W
RSL8-MCT IES SPEC BRCH	8"	1300LM	3000K/4000K/5000K	18W
SSL12-MCT IES BRCH SPEC	12"	2100LM	3000K/4000K/5000K	28W
SSL4-MCT IES SPEC BRCH	4"	675-720LM	3000K/4000K/5000K	9W		OPT-EM-DL1EXT
RSL4-TRM-ORB SPEC					4" Clip-on Trim, Oil-rubbed Bronze
RSL4-TRM-CU SPEC					4" Clip-on Trim, Copper
RSL4-TRM-BK SPEC					4" Clip-on Trim, Black
RSL4-TRM-BZ SPEC					4" Clip-on Trim, Bronze
RSL6-TRM-BK SPEC					6" Clip-on Trim, Black
RSL4-TRM-CH SPEC					4" Clip-on Trim, Chrome
RSL6-TRM-ORB SPEC					6" Clip-on Trim, Oil-rubbed Bronze
RSL4-TRM-BN SPEC					4" Clip-on Trim, Brushed Nickel
RSL6-TRM-CU SPEC					6" Clip-on Trim, Copper
RSL6-TRM-BZ SPEC					6" Clip-on Trim, Bronze
RSL6-TRM-BN SPEC					6" Clip-on Trim, Brushed Nickel
RSL6-TRM-CH SPEC					6" Clip-on Trim, Chrome
SSL4-TRM-BK SPEC					4" Clip-on Trim, Black
SSL4-TRM-CU SPEC					4" Clip-on Trim, Copper
SSL4-TRM-ORB SPEC					4" Clip-on Trim, Oil-rubbed Bronze
SSL4-TRM-CH SPEC					4" Clip-on Trim, Chrome
SSL4-TRM-BZ SPEC					4" Clip-on Trim, Bronze
SSL4-TRM-BN SPEC					4" Clip-on Trim, Brushed Nickel
SSL6-TRM-BK SPEC					6" Clip-on Trim, Black
SSL6-TRM-ORB SPEC					6" Clip-on Trim, Oil-rubbed Bronze
SSL6-TRM-CU SPEC					6" Clip-on Trim, Copper
SSL6-TRM-BZ SPEC					6" Clip-on Trim, Bronze
SSL6-TRM-BN SPEC					6" Clip-on Trim, Brushed Nickel
RSL8-RI SPEC					8" round Rough-in
RSL3-MCT-BN SPEC BRCH	3"	420LM	3000K/4000K/5000K	6W		OPT-EM-DL1EXT
RSL3-MCT-ORB SPEC BRCH	3"	420LM	3000K/4000K/5000K	6W		OPT-EM-DL1EXT
RSL10-MCT SPEC BRCH	10"	1500LM	3000K/4000K/5000K	20W		OPT-EM-DL1EXT
RSL3-MCT5 IES SPEC BRCH	3"	400LM	2700K/3000K/3500K/4000K/5000K	6W		OPT-EM-DL1EXT
RSL3-MCT5-BN SPEC BRCH	3"	400LM	2700K/3000K/3500K/4000K/5000K	6W		OPT-EM-DL1EXT
RSL3-MCT5-ORB SPEC BRCH	3"	400LM	2700K/3000K/3500K/4000K/5000K	6W		OPT-EM-DL1EXT
RSL4-MCT5 IES SPEC BRCH	4"	630LM	2700K/3000K/3500K/4000K/5000K	9W		OPT-EM-DL1EXT
RSL4-MCT5-ORB SPEC BRCH	4"	630LM	2700K/3000K/3500K/4000K/5000K	9W		OPT-EM-DL1EXT
RSL6-MCT5 SPEC IES BRCH	6"	1125LM	2700K/3000K/3500K/4000K/5000K	15W		OPT-EM-DL1EXT
RSL6-MCT5-ORB SPEC IES BRCH	6"	1125LM	2700K/3000K/3500K/4000K/5000K	15W		OPT-EM-DL1EXT
RSL8-MCT5 IES SPEC INST	8"	1350LM	2700K/3000K/3500K/4000K/5000K	18W		OPT-EM-DL1EXT
RSL10-MCT5 SPEC BRCH	10"	1500LM	2700K/3000K/3500K/4000K/5000K	20W		OPT-EM-DL1EXT
SSL4-MCT5 IES SPEC BRCH	4"	630LM	2700K/3000K/3500K/4000K/5000K	9W		OPT-EM-DL1EXT
SSL6-MCT5 IES SPEC BRCH	6"	1125LM	2700K/3000K/3500K/4000K/5000K	15W		OPT-EM-DL1EXT
SSL8-MCT5 IES SPEC	8"	1350LM	2700K/3000K/3500K/4000K/5000K	15W		OPT-EM-DL1EXT
SSL12-MCT5 SPEC BRCH	12"	1800LM	2700K/3000K/3500K/4000K/5000K	4W		OPT-EM-DL1EXT
RSL12-MCT5 SPEC IES BRCH	12"	1800LM	2700K/3000K/3500K/4000K/5000K	28W		OPT-EM-DL1EXT
RSL-EXT-10FT-MCT SPEC					10 Ft. Extension Cable For use with all Slim Light

ACCESSORIES

Product Name	Description
E26-CONVERTER	Includes Medium Base E-26 Screw-in Adapter That Fits Any Standard
RSL-EXT-10FT-MCT SPEC	10 Ft. Extension Cable For use with all Slim Light
SSL-346-RIBH SPEC	3",4",6" (Adjustable) Square Galvanized Plate with Bar Hangers
