 | FDL-10-MCT5 | - :: Construction: Spun aluminum with brushed nickel powder coat finish
- :: LED: Seoul DOB (Driver On Board) Technology
- :: Optics: White translucent acrylic lens
- :: 1" deep
- :: Voltage: 120V AC
- :: Dimmable down to 10% using an approved dimmer
- :: Power factor: 90% +
- :: Suitable for damp locations when gasket is used
- :: Maximum Ambient Temperature: 104°F
- :: ETL-listed
- :: Energy Star-rated
| |  SPEC  IES |
 | LRS-M1-MCT-P-ORB | - :: Voltage: 120V AC 60Hz
- :: Wattage: 12W
- :: Power Factor: >0.90
- :: Efficacy: 41 LPW
- :: Oil-Rubbed Bronze Finish
- :: DC Button Photocell on top of the Mounting Plate
- :: Inside Frosted Lens & External Clear Lens
- :: Operating Temperature: -4ºF to 104ºF
- :: 7-Year Warranty
- :: IP42, Suitable for Wet Location
- :: Total Lumens: 500LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 90° x 110°
- :: Rated Life: 70,000 Hrs.
| | |
 | LDAP-10-MCT5 | - :: Spun Steel Housing (Black Finish)
- :: 10-inch PMMA Acrylic Glass Panel
- :: MCT: Multi CCT (switch is under the canopy)
- :: Dimming: TRIAC Dimming (Dimmable Down to 5% compatible with TRIAC & ELV dimmers)
- :: Lumens: 700LM/900LM
- :: Wattage: 12W/18W
- :: Voltage: 120V AC 50/60Hz
- :: Efficacy: 50LM/W / 58LM/W
- :: Beam Angle: 360°
- :: Power Factor: >0.90
- :: Color Rendering Index: CRI ≥ 90
- :: Color Temp: 2700K/3000K/3500K/4000K/5000K
- :: Lifespan: 50,000 hours
- :: 5-year warranty
- :: IP Rating: IP20, Indoor only
| | SPEC BRCH |
 | CXES-10-30W-MCTP | - :: Wattage: 10W/20W/30W
- :: Input Current: 0.6A MAX
- :: Input Voltage: 120-277VAC 50/60Hz
- :: Power Factor: >0.90
- :: LPW: 130LPW
- :: Stamped Galvanized Steel
- :: Four 1/2” Threaded Hubs Located On Four SidesOf The Housing
- :: Prismatic Polycarbonate Lens
- :: Lifespan: 70000 Hrs.
- :: Operating Temperature: -40°F ~ 104°F
- :: Suitable For Damp Locations
- :: 7-year Warranty
- :: MCTP: Multi-CCT and Power Switch Is In The Fixture
- :: Dimming: 0~10V dimmable
- :: LED Type/ Brand: LUMILEDS 2835LED
- :: Total Lumens: 3900LM Max.
- :: Color Temperature: 3000K/4000K/5000K
- :: Color Rendering index: >70
- :: Beam Angle: 150°
- :: Lifespan: 70000 Hrs.
| | SPEC INST |
 | LSC-10-MCTP-BN | - :: Voltage: 120V AC 50/60Hz
- :: Wattage: 9W/12W/15W
- :: Power Factor: >0.9
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 80LPW
- :: Finish: Brushed Nickel
- :: Steel Housing
- :: Lens Type: Polycarbonate Lens
- :: Operating Temperature: -4°F to 113°F
- :: IP20, Suitable For Damp Location
- :: 5-Year Warranty
- :: Dimming: TRIAC Dimming
- :: MCTP: Multi Color Temperature and Power(SelectableSwitch Inside Fixture)Total Lumens: 1200LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 130°
| | SPEC INST |
 | WAEW-4FT-30-50W-MCTP-D | - :: Voltage: 120-277V AC 60Hz
- :: Wattage: 30W/40W/50W
- :: Factor: >0.99
- :: Efficacy: 120 LPW
- :: White Finish
- :: Housing: Die-formed Cold Rolled Steel With Powder Coated White
- :: Installation: Ceiling-Mounted
- :: Operating temperature: -22°F~104°F
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Lens: Polycarbonate Lens
- :: Total Lumens: 6000LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Multi-CCT (Selectable Switch Inside fFxture)
- :: Color Rendering Index: CRI ≥ 82
- :: Life Span: 50,000 hrs
| | SPEC IES |
 | LDS-MCT-D | - :: Housing: Steel base with die-cast rings (gray finish)
- :: High transmission frosted plastic lens with excellent distribution and uniformity
- :: Direct replacement of fluorescent
- :: Multi CCT (Selectable switch on the LED board)
- :: Dimming: TRIAC Dimming (using Standard TRIAC LED Dimmers)
- :: Lumens: 1200LM
- :: Wattage: 12W
- :: Voltage: 120V AC 50/60Hz
- :: Output Voltage: 36VDC
- :: Total Harmonic Distortion: ≤15%
- :: Efficacy: 100LPW
- :: Power Factor: >0.90
- :: Maximum Ambient Temperature: 50°F ~ 113°F
- :: Beam Angle: 120°
- :: Color Rendering Index: CRI ≥ 80
- :: Color Temp: 3000K/4000K/5000K
- :: Lifespan: 50,000 hours
- :: Suitable for Wet Locations
| | |
 | LFX-SM-10-30W-30K-KN | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: Selectable Wattages (10W/15W/20W/30W)
- :: Power Factor: >0.9
- :: Efficacy: 130 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 90° Adjustable 1/2” Knuckle Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Total Lumens: 4080LM Max.
- :: Color Temperature: 3000K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | LFX-SM-10-30W-MCTP-TR | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: 10W/15W/20W/30W
- :: Power Factor: >0.9
- :: Efficacy: 130 LP
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficienc
- :: High Conductive Aluminum LED Board
- :: 270° Adjustable Yoke Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Multi-CCT Power - The Switch is on the Bottom of the Fixture
- :: Total Lumens: 3900LM Max
- :: Color Temperature: 3000K/4000K/5000K/5700K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | LFX-SM-10-30W-30K-TR | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: Selectable Wattages (10W/15W/20W/30W)
- :: Power Factor: >0.9
- :: Efficacy: 130 LP
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 270° Adjustable Yoke Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Total Lumens: 4080LM Max.
- :: Color Temperature: 3000K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | LFX-SM-10-30W-MCTP-KN | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: 10W/15W/20W/30W
- :: Power Factor: >0.9
- :: Efficacy: 130 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 90° Adjustable 1/2” Knuckle Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Multi-CCT Power - The Switch is on the Bottom of the Fixture
- :: Total Lumens: 3900LM Max.
- :: Color Temperature: 3000K/4000K/5000K/5700K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | SCXT-2FT-10-20W-MCTP-D-DL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 10W/15W/20W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LM/W
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Custom Colors Available
- :: Lens Snaps into Housing
- :: Mounting Options: Surface, Suspended, Recessed
- :: IP Rating: IP54
- :: Each Fixture Comes With a 6-1/2” Pre-Installed Cable With Male RJ11 Connector Plugs Right Into The Driver
- :: External Driver needed. Calculate the total wattage and pick adequate driver(s) as power supply. each driver has 4 ports for 4 separate fixtures.
- :: Do not exceed the maximum wattage of the driver
- :: Order The SCXT-TGRID-SP1 To Install The Driver On Top Of a T-Bar. Or Install The Driver On a Joist
- :: Two T-Bar clips attached on top of the fixture ready to install on the grid:; Can be linked (W/ endcap on, not seamless) coupling bracket incl.
- :: Operating Temperature: -13°F~104°F
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 1100M/1650LM/2200
| | |
 | HL2R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | LRS-M2-MCT-P-ORB | - :: Voltage: 120V AC 60Hz
- :: Wattage: 12W
- :: Power Factor: >0.90
- :: Efficacy: 41 LPW
- :: Oil-Rubbed Bronze Finish
- :: DC Button Photocell on top of the Mounting Plate
- :: Inside Frosted Lens & Ornament Guard
- :: Operating Temperature: -4ºF to 104ºF
- :: 7-Year Warranty
- :: IP42, Suitable for Wet Location
- :: Total Lumens: 500LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 90° x 110°
- :: Rated Life: 70,000 Hrs.
| | |
 | LDS-MCT-D-BZ | - :: Housing: Steel base with die-cast rings (bronze finish)
- :: High-transmission frosted plastic lens with excellent distribution and uniformity
- :: Direct replacement of flourescent
- :: Multi CCT (Selectable switch on the LED board)
- :: Dimming: TRIAC Dimming (using Standard TRIAC LED Dimmers)
- :: Lumens: 1200LM
- :: Wattage: 12W
- :: Voltage: 120V AC 50/60Hz
- :: Output Voltage: 36VDC
- :: Total Harmonic Distortion: ≤15%
- :: Efficacy: 100LPW
- :: Power Factor: >0.90
- :: Maximum Ambient Temperature: 50°F ~ 113°F
- :: Beam Angle: 120°
- :: Color Rendering Index: CRI ≥ 80
- :: Color Temp: 3000K/4000K/5000K
- :: Lifespan: 50,000 hours
- :: Suitable for Wet Locations
| | |
| LFX-SM-10-30W-40K-TR | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: Selectable Wattages (10W/15W/20W/30W)
- :: Power Factor: >0.9
- :: Efficacy: 130 LP
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 270° Adjustable Yoke Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Total Lumens: 4080LM Max.
- :: Color Temperature: 4000K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
| WAEW-4FT-30-50W-MCTP-D-EM-SEN | - :: Voltage: 120-277V AC 60Hz
- :: Wattage: 30W/40W/50W
- :: Factor: >0.99
- :: Efficacy: 120 LPW
- :: White Finish
- :: Housing: Die-formed Cold Rolled Steel With Powder Coated White
- :: Installation: Ceiling-Mounted
- :: Operating temperature: -22°F~104°F
- :: 5-Year Warranty
- :: Detection Range: 17Ft. / 360°
- :: Mounting Height: 25Ft. Max.
- :: DIP Settings switch on The Sensor
- :: Optional Remote Control (WEC-3RC)
- :: Output Power: 9W
- :: Output Voltage: 48V
- :: Li-Ion Battery / >90 Minutes Emergency Operation
- :: Test Button Installed on The Side of The Fixture
- :: Dimmable: 0~10V Dimming
- :: Lens: Polycarbonate Lens
- :: Total Lumens: 6000LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 82
- :: Life Span: 50,000 hrs.
| | SPEC IES |
| LFX-SM-10-30W-40K-KN | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: Selectable Wattages (10W/ 15W/ 20W/ 30W)
- :: Power Factor: >0.9
- :: Efficacy: 130 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 90° Adjustable 1/2” Knuckle Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Total Lumens: 4080LM Max
- :: Color Temperature: 4000K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | DLST6-MCT5-IP65 | - :: Voltage: 120V AC
- :: Power Factor: >0.90
- :: Wattage: 10W
- :: Efficacy: 100 LPW
- :: White Finish
- :: Polycarbonate Housing
- :: Fits on 4” Octagonal (4O) or 3” Octagonal (3O) Electrical Boxes
- :: Recessed Mounting Springs & Kit included
- :: Maximum Ambient Temperature: -4°F to 104°F
- :: IP65, Suitable for wet location
- :: 5-Year Warranty
- :: Lens: White Translucent Acrylic
- :: MCT: The Switch is On The LED Board Under The Lens
- :: LED: Unique DOB (Driver On Board) LED BoardEnclosed in Clear PC Cover for Better Damp LocationPerformance
- :: Dimming: TRIAC Dimming (Using Standard TRIAC LED Dimmers)
- :: Total Lumens: 1000LM
- :: Color Temperatures: 2700K/3000K/3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Rated life: 50,000 hrs
- :: Beam Angle: 120°
| | SPEC |
 | ULR-IN-PIDR-72W | - :: Input voltage: 100~240VAC, 50/60Hz
- :: AC Input Current: Max 1A
- :: Output power: 72W
- :: Output DC Voltage: 24VDC
- :: Min Load: 3A
- :: Rated Load: 3A
- :: Line Regulation: ± 5%
- :: Load Regulation: ± 5%
- :: Efficiency: 83% Min
- :: Turn on delay time: 2Sec Max. at 115VAC & Max Load
- :: Rise time: 40mS Min. at 115VAC & Max Load
- :: Hold up time: 5mS Min. at 115VAC & Max Load
- :: Male 24V connector included
- :: Operating Temperature: 32°F to 104°F
- :: Protection Function: Short Circuit Test, Over current protection, Over Voltage Protection
- :: Relative Humidity: 5% to 90% RH, 72Hrs, Full Load , Normal operating.
- :: Ripple and Noise: 150mV p-p
| | SPEC |
 | SCX4-IP66-SUR-8FT-80-160W-MCTP | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W/120W/160W
- :: Power Factor: >0.95
- :: LPW: 110
- :: Total Harmonic Distortion: ≤ 19 %
- :: 6FT. Lead 18/5 AWG SJTW on One Side
- :: 1FT. Lead 18/5 AWG SJTW on The Other Side For DaisyChaining. The Cord Can be Tucked in If Not Needed,Weatherproof 1/2” NPT Plug Provided to Cover The Hub.
- :: All Wires Are Capped
- :: Two Steel Compression Connectors Provided.
- :: Surface Mounting Brackets with Screws & Anchors Included
- :: Low Profile Modern Design
- :: Aluminum Housing With Sandy White Finish
- :: Mounting Options: Surface
- :: IP Rating: IP66 Wet Location Only
- :: Operating Temperature: -22°F to +104°F
- :: 5-Year Warranty
- :: MCTP: Multi Color Temperature and Power (Select-able Switch On Fixture)
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 17600LM Max.
- :: Color Temperatures: 3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 105°(H) x 103.7°(V)
| | |
| LRS-M-RL-FG | - :: Replacement Default Frosted Lens For LRS-M Series
| | INST BRCH |
| WAEW-4FT-30-50W-MCTP-D-SEN | - :: Voltage: 120-277V AC 60Hz
- :: Wattage: 30W/40W/50W
- :: Factor: >0.99
- :: Efficacy: 120 LPW
- :: White Finish
- :: Housing: Die-formed Cold Rolled Steel With Powder Coated White
- :: Installation: Ceiling-Mounted
- :: Operating temperature: -22°F~104°F
- :: 5-Year Warranty
- :: Detection Range: 17Ft. / 360°
- :: Mounting Height: 25Ft. Max.
- :: DIP Settings switch on The Sensor
- :: Optional Remote Control (WEC-3RC)
- :: Dimmable: 0~10V Dimming
- :: Lens: Polycarbonate Lens
- :: Total Lumens: 6000LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 82
- :: Life Span: 50,000 hrs.
| | SPEC IES |
| LFX-SM-10-30W-50K-KN | - :: Die-cast Aluminium Housing with Powder Coast Finish (Dark Bronze)
- :: 90° Adjustable 1/2" Knuckle Mount
- :: Multi-CCT Power: Switches at the bottom of the fixture
- :: Lens: Optical Type III
- :: Lumens Range: 1300LM-4080LM
- :: Wattage: 10/15/20/30
- :: Voltage: 120-277V AC 50-60Hz
- :: Efficacy: 130LPW
- :: Power Factor: >0.9
- :: Operating Temp: -40°F to 104°F
- :: Beam Angle: 90° x 120°
- :: Color Rendering Index: CRI ≥ 82
- :: 7-year warranty
- :: IP Rating: IP65, Wet Location
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Total Lumens: 4080LM Max
- :: Color Temperature: 5000K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
| LFX-SM-10-30W-50K-TR | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: Selectable Wattages (10W/15W/20W/30W)
- :: Power Factor: >0.9
- :: Efficacy: 130 LP
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 270° Adjustable Yoke Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Total Lumens: 4080LM Max.
- :: Color Temperature: 5000K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | FLVXPRO-MD-10-30W-MCTPB-BR | - :: Voltage: 12V AC/DC
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Input current: 1A Max
- :: Efficacy: 90 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish(Dark Bronze)
- :: DC Button Photocell with ON/OFF switch Included
- :: Solid State Lighting Technology for Long Life, NoMaintenance Needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 8-1/2” PC Spike Included
- :: 1/2” Threaded Knuckle Stem
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Rotatable Shroud with Set Screw
- :: 7-Year Warranty
- :: Dimmable: Non Dimmable
- :: Total lumens: 2700 LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 25° to 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC |
 | LFX-SM-10-30W-MCTP-TR-SV | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: 10W/15W/20W/30W
- :: Power Factor: >0.9
- :: Efficacy: 130 LP
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficienc
- :: High Conductive Aluminum LED Board
- :: 270° Adjustable Yoke Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Multi-CCT Power - The Switch is on the Bottom of the Fixture
- :: Total Lumens: 3900LM Max
- :: Color Temperature: 3000K/ 4000K/ 5000K/ 5700K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | LFX-SM-10-30W-MCTP-KN-BK | - :: Voltage: 120~277V AC/50~60 Hz
- :: Wattage: 10W/15W/20W/30W
- :: Power Factor: >0.9
- :: Efficacy: 130 LP
- :: Die-cast Aluminum Housing with Powder Coat Finish (Silver Finish)
- :: Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 90° Adjustable 1/2” Knuckle Mount
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Dimming: 0~10V Dimmable
- :: Optic Lens Type: III
- :: Cord type: 13” #18 AWG stranded wires
- :: Multi-CCT Power - The Switch is on the Bottom of the Fixture
- :: Total Lumens: 3900LM Max.
- :: Color Temperature: 3000K/ 4000K/ 5000K/ 5700K
- :: Color Rendering Index: ≥ 82
- :: Beam Angle: 120°X 90°
| | |
 | SCX4-3FT-30W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 30W
- :: Power Factor: >0.95
- :: LPW: 108/119/111/113
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Mouning Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Adjustable Suspension Brackets Provided on Top of the Fixtures
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 3604LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | LRS-M-RL-BG | - :: Replacement Default Bubble Glass Lens For LRS-M Series
| | INST BRCH |
 | CRLE8-10-22W-MCTP-WH | - :: Voltage: 120-277V AC
- :: Output Voltage: 36VDC
- :: Power Factor: >0.90
- :: Wattage: 10W/15W/22W
- :: Efficacy: 100 LPW
- :: Total Harmonic Distortion: ≤15 %
- :: 2FT Flex Whip With Push-in Connector
- :: 16” Earthquake Safety Cable Incl.
- :: Mounting Options: Recessed
- :: Temperature Rating: Designed To Operate inTemperatures 113°F
- :: No IC-Rated
- :: Suitable For Damp Locations
- :: 5-Year Warranty
- :: MCTP: The Switch Is On The Light Engine
- :: Dimming: 0~10V Dimmable
- :: Total Lumens: 2200LM Max.
- :: Color Temperature: 3000K/4000K/5000K
- :: Color Rendering index: >80
- :: Beam Angle: 100°-110°
- :: Rated Life: 50,000 hrs
| | SPEC IES |
| CXES-10-30W-MCTP-EM | - :: Wattage: 10W/20W/30W
- :: Input Current: 0.6A MAX
- :: Input Voltage: 120-277VAC 50/60Hz
- :: Power Factor: >0.90
- :: LPW: 130LPW
- :: Stamped Galvanized Steel
- :: Four 1/2” Threaded Hubs Located On Four SidesOf The Housing
- :: Prismatic Polycarbonate Lens
- :: Lifespan: 70000 Hrs.
- :: Operating Temperature: -40°F ~ 104°F
- :: Suitable For Damp Locations
- :: 7-year Warranty
- :: Output Power: 8W
- :: Output Voltage: 48V
- :: Li-Ion Battery / >90 Minutes Emergency Operation
- :: Test Button Installed on The Side of The Fixture
- :: MCTP: Multi-CCT and Power Switch Is In The Fixture
- :: Dimming: 0~10V dimmable
- :: LED Type/ Brand: LUMILEDS 2835LED
- :: Total Lumens: 3900LM Max.
- :: Color Temperature: 3000K/4000K/5000K
- :: Color Rendering index: >70
- :: Beam Angle: 150°
- :: Lifespan: 70000 Hrs
| | SPEC INST |
 | FLVXPRO-MD-10-30W-MCTPB-BK | - :: Voltage: 12V AC/DC
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Input current: 1A Max
- :: Efficacy: 90 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish(Black)
- :: DC Button Photocell with ON/OFF switch Included
- :: Solid State Lighting Technology for Long Life, NoMaintenance Needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: 8-1/2” PC Spike Included
- :: 1/2” Threaded Knuckle Stem
- :: IP Rating: IP65
- :: Operating Temperature: -40°F to 104°F
- :: Suitable for Wet Locations
- :: Rotatable Shroud with Set Screw
- :: 7-Year Warranty
- :: Dimmable: Non Dimmable
- :: Total lumens: 2700 LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 25° to 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC |
| LDS-MCT5-DT-SIL | - :: Voltage: 120V AC 50/60Hz
- :: Output Voltage: 36VDC
- :: Power Factor: >0.90
- :: Wattage: 15W
- :: Efficacy: 65 LPW
- :: Total Harmonic Distortion: ≤15 %
- :: Silver Finish
- :: Housing: Steel base with Die-cast Rings
- :: High-Transmission Frosted Plastic Lens With Excellent Distribution and Uniformity
- :: Maximum Ambient Temperature: 50~113°F
- :: Rated life: 50,000 Hrs
- :: Wet Location
- :: Dimming: TRIAC Dimming (Using Standard TRIAC LED Dimmers)
- :: Total Lumens: 980LM
- :: Color Temperatures: 2700K/3000K/3500K/4000K/5000K
- :: Multi CCT (Selectable Switch on the LED Board )
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 120°
| | |
 | SCXT-2FT-10-20W-MCTP-D-FL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 10W/15W/20W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LM/W
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Custom Colors Available
- :: Lens Snaps into Housing
- :: Mounting Options: Surface, Suspended, Recessed
- :: IP Rating: IP54
- :: Each Fixture Comes With a 6-1/2” Pre-Installed Cable With Male RJ11 Connector Plugs Right Into The Driver
- :: External Driver needed. Calculate the total wattage and pick adequate driver(s) as power supply. each driver has 4 ports for 4 separate fixtures.
- :: Do not exceed the maximum wattage of the driver
- :: Order The SCXT-TGRID-SP1 To Install The Driver On Top Of a T-Bar. Or Install The Driver On a Joist
- :: Two T-Bar clips attached on top of the fixture ready to install on the grid
- :: Can be linked (W/ endcap on, not seamless) coupling bracket incl.
- :: Operating Temperature: -13°F~104°F
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 1100LM/1650LM/220
| | |
FT%20Resized.jpg%3Falt%3Dmedia&w=3840&q=75&dpl=dpl_HkFkVFhPPYEhtuSX6Cvjgd277eCx) | SCX4-IP66-ACPT-10FT | - :: SCX4-IP66 10Ft Ac Pigtail With Female Wet Loc. Connector
| | SPEC |
 | LRS-M-RL-CG | - :: Replacement Crackled Glass Lens For LRS-M Series
| | INST BRCH |
 | LDS-MCT5-DT-BK | - :: Voltage: 120V AC 50/60Hz
- :: Output Voltage: 36VDC
- :: Power Factor: >0.90
- :: Wattage: 15W
- :: Efficacy: 65 LPW
- :: Total Harmonic Distortion: ≤15 %
- :: Black Finish
- :: Housing: Steel base with Die-cast Rings
- :: High-Transmission Frosted Plastic Lens With Excellent Distribution and Uniformity
- :: Maximum Ambient Temperature: 50~113°F
- :: Rated life: 50,000 Hrs
- :: Wet Location
- :: Dimming: TRIAC Dimming (Using Standard TRIAC LED Dimmers)
- :: Total Lumens: 980LM
- :: Color Temperatures: 2700K/3000K/3500K/4000K/5000K
- :: Multi CCT (Selectable Switch on the LED Board)
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 120°
| | |
 | FLDXPRO-MD-10-30W-MCTPB-BR | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 95 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish(Dark Bronze)
- :: DC Button Photocell with ON/OFF switch Included
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 2850LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 25° to 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC IES |
 | SCX4-6FT-60W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 60W
- :: Power Factor: >0.95
- :: LPW: 113/118/120/121
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Mounting Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Adjustable Suspension Brackets Provided on Top of the Fixtures
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 7208LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Bram Angle: 104.8°(H) x 100.5°(V)
| | |
 | FLDXPRO-MD-10-30W-MCTPB-BK | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 95 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish(Black)
- :: DC Button Photocell with ON/OFF switch Included
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 2850LM Max.:; Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 25° to 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC IES |
 | HL4DW-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outswith strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
%20main%20front%2010-30w%20resized.jpg%3Falt%3Dmedia&w=3840&q=75&dpl=dpl_HkFkVFhPPYEhtuSX6Cvjgd277eCx) | CXES-10-30W-MCTP-WH | - :: Wattage: 10W/20W/30W
- :: Input Current: 0.6A MAX
- :: Input Voltage: 120-277VAC 50/60Hz
- :: Power Factor: >0.90
- :: LPW: 130LPW
- :: Stamped Galvanized Steel
- :: Four 1/2” Threaded Hubs Located On Four Sides OfThe Housing
- :: Prismatic Polycarbonate Lens
- :: Lifespan: 70000 Hrs
- :: Operating Temperature: -40°F ~ 104°F
- :: Suitable For Damp Locations
- :: 7-year Warranty
- :: MCTP: Multi-CCT and Power Switch Is In The Fixture
- :: Dimming: 0~10V dimmable
- :: LED Type/ Brand: LUMILEDS 2835LED
- :: Total Lumens: 3900LM Max.
- :: Color Temperature: 3000K/4000K/5000K
- :: Color Rendering index: >70
- :: Beam Angle: 150°
- :: Lifespan: 70000 Hrs
| | SPEC INST |
 | CRE-MP-10-30K-SIL | - :: Voltage: 120~277V AC
- :: Wattage: 5W/10W/15W/20W
- :: Power Factor: 0.95
- :: Efficacy: 90LM/W
- :: Patent-Pending designs with different light engines (base) and interchangeable designer trims expand the series to multiple color temperatures and models
- :: Series can be stocked as separate engines and trims to offer a versatile collection at the store level
- :: Die-cast Aluminum weatherproof housing, steel backplate, Aluminum Trim
- :: Operating temperature: -40°F to 104°F
- :: IP Rating: IP65, Suitable for wet locations
- :: 7-Year Warranty
- :: Multi-Power (the switch is inside fixture)
- :: Dimming: 0-10V Dimming
- :: Total lumens: 1800LM Max.
- :: Color temperature: 3000K/4000K/5000K
- :: Color rendering index: >90
- :: Lifespan: 70,000 hr.
| | |
 | CRE-MP-10-30K-BR | - :: Voltage: 120~277V AC
- :: Wattage: 5W/10W/15W/20W
- :: Power Factor: 0.95
- :: Efficacy: 90LM/W
- :: Patent-Pending designs with different light engines (base) and interchangeable designer trims expand the series to multiple color temperatures and models
- :: Series can be stocked as separate engines and trims to offer a versatile collection at the store level
- :: Die-cast Aluminum weatherproof housing, steel backplate, Aluminum Trim (Dark Bronze or Silver)
- :: Operating temperature: -40°F to 104°F
- :: IP Rating: IP65, Suitable for wet locations
- :: 7-Year Warranty
- :: Multi-Power (the switch is inside fixture)
- :: Dimming: 0-10V Dimming
- :: Total lumens: 1800LM Max.
- :: Color temperature: 3000K/4000K/5000K
- :: Color rendering index: >90
- :: Beam Angle: 30°
- :: Lifespan: 70,000 hr.
| | |
 | FLDX-MD-10-30W-30K-BR | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 120 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: MP: Multi Power switch on the back of the fixture
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 3700LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC |
| CRE-MP-10-40K-SIL | - :: Voltage: 120~277V AC
- :: Wattage: 5W/10W/15W/20W
- :: Power Factor: 0.95
- :: Efficacy: 90LM/W
- :: Patent-Pending designs with different light engines (base) and interchangeable designer trims expand the series to multiple color temperatures and models
- :: Series can be stocked as separate engines and trims to offer a versatile collection at the store level
- :: Die-cast Aluminum weatherproof housing, steel backplate, Aluminum Trim
- :: Operating temperature: -40°F to 104°F
- :: IP Rating: IP65, Suitable for wet locations
- :: 7-Year Warranty
- :: Multi-Power (the switch is inside fixture)
- :: Dimming: 0-10V Dimming
- :: Total lumens: 1800LM Max.
- :: Color temperature: 3000K/4000K/5000K
- :: Color rendering index: >90
- :: Lifespan: 70,000 hr.
| | |
 | CRE-MP-10-40K-BR | - :: Voltage: 120~277V AC
- :: Wattage: 5W/10W/15W/20W
- :: Power Factor: 0.95
- :: Efficacy: 90LM/W
- :: Patent-Pending designs with different light engines (base) and interchangeable designer trims expand the series to multiple color temperatures and models
- :: Series can be stocked as separate engines and trims to offer a versatile collection at the store level
- :: Die-cast Aluminum weatherproof housing, steel backplate, Aluminum Trim
- :: Operating temperature: -40°F to 104°F
- :: IP Rating: IP65, Suitable for wet locations
- :: 7-Year Warranty
- :: Multi-Power (the switch is inside fixture)
- :: Dimming: 0-10V Dimming
- :: Total lumens: 1800LM Max.
- :: Color temperature: 3000K/4000K/5000K
- :: Color rendering index: >90
- :: Beam Angle: 30°
- :: Lifespan: 70,000 hr.
| | |
 | WA-2FT-10-20W-MCTP | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 10W/15W/20W
- :: Power Factor: >0.95
- :: Efficacy: 110 LPW
- :: White Finish
- :: Housing: Die-Formed Heavy Gauge Cold Rolled SteelWith Powder-Coated White
- :: Steel Thickness: 24 Gauge
- :: Installation: Ceiling-Mounted
- :: Optional Battery Backup Available for 30W Units
- :: Operating Temp: -22ºF~107ºF
- :: IP Rating: IP40,Suitable for Damp Locations
- :: 5-Year Warranty
- :: Multi-CCT and Power: Multi Color Temperature &Multi Power/Wattage (Selectable)
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 2200LM
- :: Color Temperatures: 3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 82
- :: 50,000 Hours Rated Life
| | SPEC |
 | FLDX-MD-10-30W-30K-BK | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 120 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Black)
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: MP: Multi Power switch on the back of the fixture
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 3700LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC |
 | ULR-IN-98F-HO-35K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8” on center, 19 per foot,0.23wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 310~350LM per ft.
- :: Color temperature: 3500K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
 | ULR-IN-98F-XHO-35K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 8.8W per ft.
- :: Max Run: 11ft.
- :: Efficacy: 70~79LM/W per ft.
- :: Cutting increment: Every 2 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 1/3” on center, 37 per foot,0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 620~700LM per ft.
- :: Color temperature: 3500K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | BRCH SPEC |
| CRE-MP-10-50K-BR | - :: Voltage: 120~277V AC
- :: Wattage: 5W/10W/15W/20W
- :: Power Factor: 0.95
- :: Efficacy: 90LM/W
- :: Patent-Pending designs with different light engines (base) and interchangeable designer trims expand the series to multiple color temperatures and models
- :: Series can be stocked as separate engines and trims to offer a versatile collection at the store level
- :: Die-cast Aluminum weatherproof housing, steel backplate, Aluminum Trim
- :: Operating temperature: -40°F to 104°F
- :: IP Rating: IP65, Suitable for wet locations
- :: 7-Year Warranty
- :: Multi-Power (the switch is inside fixture)
- :: Dimming: 0-10V Dimming
- :: Total lumens: 1800LM Max.
- :: Color temperature: 3000K/4000K/5000K
- :: Color rendering index: >90
- :: Beam Angle: 30°
- :: Lifespan: 70,000 hr.
| | |
| CRE-MP-10-50K-SIL | - :: Voltage: 120~277V AC
- :: Wattage: 5W/10W/15W/20W
- :: Power Factor: 0.95
- :: Efficacy: 90LM/W
- :: Patent-Pending designs with different light engines (base) and interchangeable designer trims expand the series to multiple color temperatures and models
- :: Series can be stocked as separate engines and trims to offer a versatile collection at the store level
- :: Die-cast Aluminum weatherproof housing, steel backplate, Aluminum Trim
- :: Operating temperature: -40°F to 104°F
- :: IP Rating: IP65, Suitable for wet locations
- :: 7-Year Warranty
- :: Multi-Power (the switch is inside fixture)
- :: Dimming: 0-10V Dimming
- :: Total lumens: 1800LM Max.
- :: Color temperature: 3000K/4000K/5000K
- :: Color rendering index: >90
- :: Lifespan: 70,000 hr.
| | |
| FLDX-MD-10-30W-40K-BR | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 120 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: MP: Multi Power switch on the back of the fixture
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 3700LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC |
 | IGL-1W-TRM-AL-RAZ | - :: Trims for 1W In-Ground Fixtures
| | |
 | ULR-IN-98F-HO-COB-50K | - :: LED: COB480 Dotless Technology
- :: Length: 98.4FT
- :: Width: 0.39IN
- :: LEDs/Ft: 150
- :: CCT: 5000K
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 4 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 3 watts per foot
- :: Lumens: 340LM/FT
- :: CRI: 90
- :: Max run: 20'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | SPEC BRCH |
| FLDX-MD-10-30W-40K-BK | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 120 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Black)
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: MP: Multi Power switch on the back of the fixture
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 3700LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC |
 | HL6R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | SCX4-IC-MCT4 | - :: Low Profile Modern Design
- :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Lens Snaps into Housing
- :: Lens Type: Polished Aluminum Louver Lens
- :: Mounting Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Dimmable: 0~10V Dimming
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: Up Light Option Available
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | SPEC IES |
| FLDX-MD-10-30W-50K-BR | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 120 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: MP: Multi Power switch on the back of the fixture
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 3700LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 60°
- :: Lifespan: 70,000 Hrs.
| | SPEC IES |
 | HL6-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation lagging
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-BoxvUL listed for damp location.
- :: UL listed for Air Tight construction
- :: Meet Title24 requirement
- :: ETLus
| | SPEC INST |
 | FLDX-LG-10-30W-MCTP-BR | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 120 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: MCTP: Multi CCP and Power switches on the back of the fixture
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 3600LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 60°
- :: Lifespan: 70,000 Hrs.
| | IES SPEC |
 | HL6S-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation lagging
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | FLDX-LG-10-30W-MCTP-BK | - :: Voltage: 120-277V
- :: Power Factor: >0.9
- :: Wattage: 10W/20W/30W
- :: Efficacy: 120 LPW
- :: Die-cast Aluminum Housing with Powder Coat Finish (Black)
- :: Cord type: 18” SJTW 18/3 AWG cable
- :: 1/2” Threaded Knuckle Stem
- :: Operating Temperature: -40°F to 104°F
- :: IP Rating: IP65
- :: Suitable for Wet Locations
- :: 7-Year Warranty
- :: MCTP: Multi CCP and Power switches on the back of the fixture
- :: Lens Type: Plaid Tempered Glass + Aluminum Reflectors
- :: Total Lumens: 3600LM
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 60°
- :: Lifespan: 70,000 Hrs.
| | IES SPEC |
 | IGL-1W-TRM-SS-SQSQ | - :: Trims for 1W In-Ground Fixtures
| | |
 | IGL-3W-TRM-AL-RLBN | - :: Trims for 3W In-Ground Fixtures
| | |
 | IGL-3W-TRM-SS-2WY | - :: Trims for 3W In-Ground Fixtures
| | |
 | SCX-IC-40K | - :: Lumens: 787LM
- :: Color Temperatures: 4000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
| SCX-IC-50K | - :: Lumens: 854LM
- :: Color Temperatures: 5000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
 | CRLC10-60W-MCTP-D-RG | - :: Voltage: 120-277V AC 50/60Hz
- :: Wattage: 40W/50W/60W
- :: Power Factor: >0.90
- :: Efficacy: 80 LPW
- :: 10” Haze, Rose gold & White Finish TRIM
- :: Mounting Options: Recessed
- :: Temperature Rating: Designed to operate in temperatures 113°F
- :: No IC-Rated
- :: Suitable for Damp Locations
- :: 5-Year Warranty
- :: MCTP: The switch is on the light engine
- :: Dimming: 0~10V Dimmable
- :: Total lumens: 4800LM Max.
- :: Color Temperature: 3000K/3500K/4000K
- :: Color Rendering index: >80
- :: Lifespan: 50,000 hrs.
| | SPEC |
 RESIZED.jpg?alt=media)
 1 RESIZED.jpg?alt=media)
 1 RESIZED.jpg?alt=media)
