 | MSO-IP66-I | - :: Polycarbonate construction
- :: Ideal for dusk to dawn operation
- :: 1/2 NPT threads fit into 1/2” weatherproof box outlets
- :: Wet location listed (NEMA 3R rated)
- :: Full one year warranty
| |  SPEC BRCH |
 | PL12-ILDMR-BK | | | |
 | ICF4SJBB | - :: ETL Type IC Rated, complies with the requirements of the Standard(s) for Metallic Outlet Boxes (UL-514A) and are identified with the ETL Listed Mark
- :: ETL Listed for 2-Hour Fire Resistance to Meet and Exceed Strict Fire UL 263 Safety Code
- :: ETL ASTM E283/E283M-19 Air Tight certified
- :: Trims and Inserts Sold Separately
- :: Integrated Non-Combustible Insulation Acts As a Sound Barrier Minimizing Sound Transfer Between Floors
- :: Rated for Direct Contact With IC Insulation
- :: Light Fixtures Sold Separately
| | |
 | UCSENS-IR-1 | | | |
 | ULR-IN-16F-YHO-40K | - :: LED: SMD2835 chip spaced 1/3” on center, 39 LED per foot, 0.17 watts eachchip
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 2.5 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 6.7 watts per foot
- :: Lumens: 914 lumens per foot, 24 LM per LED
- :: CRI: 80
- :: Max run: 14’
- :: 120º beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 maleplug for connection to next ribbon (Prewired)
- :: Operating temperature: -4°F - 104°F
- :: IP20
- :: 5-year warranty
| | BRCH |
 | ULR-IN-16F-HO-COB-WT | - :: LED: COB Dotless Technology
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 1-1/8 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 3 watts per foot
- :: Lumens: 290-340LM/FT
- :: CRI: 90
- :: Max run: 20'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | SPEC |
 | HL2R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | ULR-IN-16F-SO-27K | - :: LED: SMD2216 chip spaced 5/8" on center, 19 per foot, 0.08 watts each chip
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 4 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 1.5 watts per foot
- :: Lumens: 100 lumens per foot, 4.73 LM per LED
- :: CRI: 90
- :: Max run: 32'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | SPEC |
 | ULR-IN-16F-HO-27K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8” on center, 19 per foot, 0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 310~350LM per ft.
- :: Color temperature: 2700K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
 | ULR-IN-HWDR-75W | - :: Input voltage: 85-264VAC, 50/60Hz
- :: AC Input Current: 100mA max
- :: Output power: 75W
- :: Output Current: 0~3.2A
- :: Output DC Voltage: 24V
- :: Setup, Rise time: 500ms, 30ms/230VAC 500ms, 30ms/115VAC at full load
- :: Hold up time: 60ms/230VAC 12ms/115VAC at full load
- :: Leakage Current: <0.75mA / 240VAC
- :: No Load power consumption<0.3W
- :: LED indicator for power on
- :: operating temperature: -22°F to 158°F
- :: Cooling by free air convection
- :: 100% full load burn-in test
- :: Withstand 5G vibration test
- :: Over voltage category III Safety Standards: UL60950-1, TUV EN60950-1, EN60335-1, EN61558-1 2 16 .1, BSMI CNS14336-1, EAC TP TC 004, AS/NZS 60950.1(by CB) approved
- :: Withstand Voltage: I/P-O/P:4KVAC, I/P-FG:2KVAC, O/P-FG:1.25KVAC
- :: Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC / 25 / 70% RH
- :: EMC Emission: Compliance to EN55032 (CISPR32) Class B, EN55014, EN61000-3-2,-3, GB/T 9254, BSMI CNS13438, EAC TP TC 020
| | SPEC |
 | SCX-2FT-20W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 20W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 2197LM/2316LM/2348LM/2390LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable with Switch Inside the Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
| ULR-IN-16F-HO-COB-27K | - :: LED: COB480 Dotless Technology
- :: Length: 16.4FT
- :: Width: 0.39IN
- :: LEDs/Ft: 146
- :: CCT: 2700K
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 4 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 3 watts per foot
- :: Lumens: 290LM/FT
- :: CRI: 90
- :: Max run: 20'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | BRCH SPEC |
 | IGL-1W-30K | - :: Stainless Steel Cover/Aluminum Housing/SS Housing/PVC Sleeve
- :: LED: COB Technology (Dimmable)
- :: Lens: Glass
- :: Wattage: 1W
- :: Lumens: 100LM
- :: Voltage: 12V AC/DC
- :: Beam Angle: 45°
- :: Color Temp: 3000K Warm White
- :: 1-year warranty
- :: IP Rating: IP67, Wet Location
| | SPEC |
 | IGLA-3W-30K-BN | - :: Voltage: 12-24V AC/DC
- :: Power Factor: >0.9
- :: Wattage: 3W
- :: Input current: 1A Max
- :: Efficacy: 106LPWDie-cast Aluminum HousingTraffic Rated: They are not likely to get damaged fromactivity around the light, including lawn care, as well asfoot and auto traffic
- :: Optical PC Flat Lens
- :: 4” PVC Sleeve with three 1/2” KO. 2 on sides, 1 on bottom
- :: Solid State Lighting Technology for Long Life, NoMaintenance Needed and High-Efficiency
- :: High Conductive Aluminum LED Board
- :: IP Rating: IP67
- :: Operating Temperature: -4°F to 104°F
- :: Suitable for Wet Locations
- :: 1-Year Warranty
- :: LED: Built in integrated LED
- :: Total lumens: 320LM
- :: Color Temperatures: 3000K
- :: Color Rendering Index: CRI ≥ 90
- :: Beam Angle: 30°
- :: Lifespan: 50,000 Hrs.
| | |
 | SCX4-IP66-SUS-4FT-40-80W-MCTP | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 40W/60W/80W
- :: Power Factor: >0.95
- :: LPW: 110
- :: Total Harmonic Distortion: ≤ 19 %
- :: Wall Mounting Kit Included
- :: Suspended With Optional Stainless Steel Down Rod Kitsor Heavy-Duty Aircraft Cables
- :: Waterproof Male & Female Connectors Pre-Installed OnThe Top Near The Two Ends
- :: Low Profile Modern Design
- :: Aluminum Housing With Sandy White Finish
- :: Mounting Options: Suspended, Wall
- :: IP Rating: IP66 Wet Location Only
- :: Operating Temperature: -22°F to +104°F
- :: 5-Year Warranty
- :: MCTP: Multi Color Temperature and Power (Select-able Switch Fixture)
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 8800LM Max.
- :: Color Temperatures: 3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 105°(H) x 103.7°(V)
| | |
 | SCX4-IP66-SUR-8FT-80-160W-MCTP | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W/120W/160W
- :: Power Factor: >0.95
- :: LPW: 110
- :: Total Harmonic Distortion: ≤ 19 %
- :: 6FT. Lead 18/5 AWG SJTW on One Side
- :: 1FT. Lead 18/5 AWG SJTW on The Other Side For DaisyChaining. The Cord Can be Tucked in If Not Needed,Weatherproof 1/2” NPT Plug Provided to Cover The Hub.
- :: All Wires Are Capped
- :: Two Steel Compression Connectors Provided.
- :: Surface Mounting Brackets with Screws & Anchors Included
- :: Low Profile Modern Design
- :: Aluminum Housing With Sandy White Finish
- :: Mounting Options: Surface
- :: IP Rating: IP66 Wet Location Only
- :: Operating Temperature: -22°F to +104°F
- :: 5-Year Warranty
- :: MCTP: Multi Color Temperature and Power (Select-able Switch On Fixture)
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 17600LM Max.
- :: Color Temperatures: 3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 105°(H) x 103.7°(V)
| | |
| SCX4-IP66-SUS-8FT-80-160W-MCTP | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W/120W/160W
- :: Power Factor: >0.95
- :: LPW: 110
- :: Total Harmonic Distortion: ≤ 19 %
- :: Wall Mounting Kit Included
- :: Suspended With Optional Stainless Steel Down Rod Kitsor Heavy-Duty Aircraft Cables
- :: Waterproof Male & Female Connectors Pre-Installed OnThe Top Near The Two Ends
- :: Low Profile Modern Design
- :: Aluminum Housing With Sandy White Finish
- :: Mounting Options: Suspended, Wall
- :: IP Rating: IP66 Wet Location Only
- :: Operating Temperature: -22°F to +104°F
- :: 5-Year Warranty
- :: MCT: Multi Color Temperature and Power (SelectableSwitch Fixture)
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 17600LM Max.
- :: Color Temperatures: 3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 105°(H) x 103.7°(V)
| | |
 | DLST6-MCT5-IP65 | - :: Voltage: 120V AC
- :: Power Factor: >0.90
- :: Wattage: 10W
- :: Efficacy: 100 LPW
- :: White Finish
- :: Polycarbonate Housing
- :: Fits on 4” Octagonal (4O) or 3” Octagonal (3O) Electrical Boxes
- :: Recessed Mounting Springs & Kit included
- :: Maximum Ambient Temperature: -4°F to 104°F
- :: IP65, Suitable for wet location
- :: 5-Year Warranty
- :: Lens: White Translucent Acrylic
- :: MCT: The Switch is On The LED Board Under The Lens
- :: LED: Unique DOB (Driver On Board) LED BoardEnclosed in Clear PC Cover for Better Damp LocationPerformance
- :: Dimming: TRIAC Dimming (Using Standard TRIAC LED Dimmers)
- :: Total Lumens: 1000LM
- :: Color Temperatures: 2700K/3000K/3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Rated life: 50,000 hrs
- :: Beam Angle: 120°
| | SPEC |
 | ULR-IN-PIDR-72W | - :: Input voltage: 100~240VAC, 50/60Hz
- :: AC Input Current: Max 1A
- :: Output power: 72W
- :: Output DC Voltage: 24VDC
- :: Min Load: 3A
- :: Rated Load: 3A
- :: Line Regulation: ± 5%
- :: Load Regulation: ± 5%
- :: Efficiency: 83% Min
- :: Turn on delay time: 2Sec Max. at 115VAC & Max Load
- :: Rise time: 40mS Min. at 115VAC & Max Load
- :: Hold up time: 5mS Min. at 115VAC & Max Load
- :: Male 24V connector included
- :: Operating Temperature: 32°F to 104°F
- :: Protection Function: Short Circuit Test, Over current protection, Over Voltage Protection
- :: Relative Humidity: 5% to 90% RH, 72Hrs, Full Load , Normal operating.
- :: Ripple and Noise: 150mV p-p
| | SPEC |
 | ULR-IN-16F-SO-30K | - :: LED: SMD2216 chip spaced 5/8" on center, 19 per foot, 0.08 watts each chip
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 4 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 1.5 watts per foot
- :: Lumens: 100 lumens per foot, 4.73 LM per LED
- :: CRI: 90
- :: Max run: 32'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | SPEC |
| IGL-1W-40K | - :: Stainless Steel Cover/Aluminum Housing/SS Housing/PVC Sleeve
- :: LED: COB Technology (Dimmable)
- :: Lens: Glass
- :: Wattage: 1W
- :: Lumens: 100LM
- :: Voltage: 12V AC/DC
- :: Beam Angle: 45°
- :: Color Temp: 4000K Natural White
- :: 1-year warranty
- :: IP Rating: IP67, Wet Location
| | SPEC |
 | SCX-4FT-40W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 40W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole onthe End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 4400LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX4-3FT-30W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 30W
- :: Power Factor: >0.95
- :: LPW: 108/119/111/113
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Mouning Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Adjustable Suspension Brackets Provided on Top of the Fixtures
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 3604LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | ULR-IN-HWDR-150W | - :: Output power: 150W
- :: Output Current: 0~6.5A
- :: Output DC Voltage: 24V
- :: Setup, Rise time: 500ms, 30ms/230VAC 500ms, 30ms/115VAC at full load
- :: Hold up time: 40ms/230VAC 35ms/115VAC at full load
- :: Leakage Current: <0.75mA / 240VAC
- :: Efficiency: 89%
- :: LED indicator for power on
- :: No load power consumption < 0.5W
- :: AC input range selected by switch
- :: Operating temperature: up to 158°F
- :: Protections: Short circuit, Overload, Over voltage, Over Temperature
- :: Cooling by free air convection
- :: Withstand 5G vibration test
- :: Over voltage category III
- :: 100% full load burn-in-test
- :: Safety Standards: UL60950-1, TUV EN60950-1, EN60335-1, EN61558-1 2 16, CCC GB4943.1, BSMI CNS14336-1, EAC TP TC 004, AS/NZS 60950.1(by CB) approved
- :: Withstand Voltage: I/P-O/P:4KVAC, I/P-FG:2KVAC, O/P-FG:1.25KVAC
- :: Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC / 77°F / 70% RH
- :: EMC Emission: Compliance to EN55032 (CISPR32) Class B, EN55014, EN61000-3-2,-3, GB/T 9254, BSM
| | SPEC |
 | SCX-3FT-30W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 30W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole onthe End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 3300LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | HL3R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
- :: ETLus
| | SPEC INST |
FT%20Resized.jpg%3Falt%3Dmedia&w=3840&q=75&dpl=dpl_2gCrdALrasdqqUyJW2ABBDEEFDen) | SCX4-IP66-ACPT-10FT | - :: SCX4-IP66 10Ft Ac Pigtail With Female Wet Loc. Connector
| | SPEC |
 | ULR-IN-16F-HO-40K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8" on center, 19 per foot, 0.23 watts each chip
- :: Total Lumens: 310~350LM per ft.
- :: Color Temperature: 4000K
- :: Color Rendering Index: 90
- :: Beam Angle: 120º
| | SPEC |
 | ULR-IP54-16F-HO-40K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Operating temperature: -4°F - 104°F
- :: IP rating: IP54
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8” on center, 19 per foot,0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 310~350LM per ft.
- :: Color temperature: 4000K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
| ULR-IN-16F-HO-COB-50K | - :: LED: COB480 Dotless Technology
- :: Length: 16.4FT
- :: Width: 0.39IN
- :: LEDs/Ft: 146
- :: CCT: 5000K
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 4 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 3 watts per foot
- :: Lumens: 340LM/FT
- :: CRI: 90
- :: Max run: 20'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | BRCH SPEC |
 | ULR-IN-16F-XHO-40K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 8.8W per ft.
- :: Max Run: 11ft.
- :: Efficacy: 70~79LM/W per ft
- :: Cutting increment: Every 2 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 1/3” on center, 37 per foot,0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 620~700LM per ft.
- :: Color temperature: 4000K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
 | SCX4-4FT-40W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 40W
- :: Power Factor: >0.95
- :: LPW: 110/112/115/122
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Mounting Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Adjustable Suspension Brackets Provided on Top of the Fixtures
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 4954LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
| SCX-6FT-60W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 60W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 6600LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX4-6FT-60W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 60W
- :: Power Factor: >0.95
- :: LPW: 113/118/120/121
- :: Total Harmonic Distortion: ≤ 20 %
- :: Low Profile Modern Design
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Mounting Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Adjustable Suspension Brackets Provided on Top of the Fixtures
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 7208LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Bram Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX-8FT-80W-MCT-D-IDL | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: LPW: 110
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 8800LM
- :: Color Temperatures: 3000K/3500K/4000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | SCX-IC-MCT4 | - :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
- :: Ambient Temperature: -13°F~104°F
- :: Dimmable: 0~10V dimmable
- :: CRI:>80
- :: Power Factor:>0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | |
IN%20Resized.jpg%3Falt%3Dmedia&w=3840&q=75&dpl=dpl_2gCrdALrasdqqUyJW2ABBDEEFDen) | SCX4-IP66-JUMP-6IN | - :: SCX4-IP66 6in Ac Jump Cable With Male And Female Wet Loc. Connector
| | SPEC |
 | ULR-IN-HWDR-350W | - :: Output power: 350W
- :: Output Current: 0~29A
- :: Output DC Voltage: 24V
- :: Setup, Rise time: 1300ms, 50ms/230VAC 1300ms, 50ms/115VAC at full load
- :: Hold up time: 16ms/230VAC 12ms/115VAC at full load
- :: Leakage Current: <2mA / 240VAC
- :: Efficiency: 83.5%
- :: LED indicator for power on
- :: No load power consumption < 0.75W
- :: AC input range selected by switch
- :: Operating temperature: up to 158°F
- :: Protections: Short circuit, Overload, Over voltage, Over Temperature
- :: Force air cooling by built-in DC fan
- :: Built –in cooling fan NO-OFF control
- :: Withstand 5G vibration test
- :: 100% full load burn-in-test
- :: Safety Standards: IEC/UL 62368-1, BSMI CNS14336-1, EAC TP TC 004,KC K60950-1 (for LRS-350-12/24 only) approved
- :: Withstand Voltage: I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
- :: Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
- :: EMC Emission: Compliance to BSMI CNS13438, EAC TP TC 020,KC KN32 KN35
| | SPEC |
| SCX-8FT-80W-MCT4-D-IND | - :: Voltage: 120-277VAC 50/60Hz
- :: Wattage: 80W
- :: Power Factor: >0.95
- :: Total Harmonic Distortion: ≤ 20 %
- :: Efficacy: 110 LPW
- :: Low Profile Modern Design
- :: Aluminum Housing With Matte White Finish
- :: Lens Type: Opal Polycarbonate Lens
- :: Lens Snaps into Housing
- :: IP Rating: IP54
- :: Operating Temperature: -13°F~104°F
- :: Suspended, Requires Suspension Cables (Not Included) See Page 2
- :: Power Cord comes out through the Suspension Hole on the End of the Fixture from the Top
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: Total Lumens: 8800LM
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Multi-CCT(Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: Up Light Option Available
- :: 50,000 Hours Rated Life
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | |
 | HL4R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outswith strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
- :: ETLus
| | SPEC INST |
 | ULR-IN-16F-HO-50K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape (9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8” on center, 19 per foot, 0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 310~350LM per ft.
- :: Color temperature: 5000K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
| ULR-IP54-16F-HO-50K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Operating temperature: -4°F - 104°F
- :: IP rating: IP54
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8” on center, 19 per foot,0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 310~350LM per ft.
- :: Color temperature: 5000K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
| ULR-IN-98F-SO-27K | - :: LED: SMD2216 chip spaced 5/8" on center, 19 per foot, 0.08 watts each chip
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 4 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 1.5 watts per foot
- :: Lumens: 100 lumens per foot, 4.73 LM per LED
- :: CRI: 90
- :: Max run: 32'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | SPEC |
 | HL4DW-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outswith strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
| ULR-IN-98F-XHO-27K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 8.8W per ft.
- :: Max Run: 11ft.
- :: Efficacy: 70~79LM/W per ft.
- :: Cutting increment: Every 2 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 1/3” on center, 37 per foot,0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 620~700LM per ft.
- :: Color temperature: 2700K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC BRCH |
 | ULR-IN-HWDR-450W | - :: Output power: 450W
- :: Output Current: 0~18.8A
- :: Output DC Voltage: 24V
- :: Setup, Rise time: 1500ms, 50ms/230VAC 1500ms, 50ms/115VAC at full load
- :: Hold up time: 16ms/230VAC 12ms/115VAC at full load
- :: Leakage Current: <2.5mA / 240VAC
- :: Efficiency: 86%
- :: LED indicator for power on
- :: AC input active surge current limiting
- :: AC input range selected by switch
- :: Operating temperature: up to 158°F
- :: Protections: Short circuit, Overload, Over voltage, Over Temperature
- :: Force air cooling by built-in DC ball bearing fan
- :: Built-in remote sense function
- :: Safety Standards: IEC/UL 62368-1, BSMI CNS14336-1, EAC TP TC 004,KC K60950-1 (for LRS-350-12/24 only) approved
- :: Withstand Voltage: I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
- :: Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
- :: EMC Emission: Compliance to BSMI CNS13438, EAC TP TC 020,KC KN32 KN35
| | SPEC |
| SCX-IC-MCT4 | - :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
- :: Ambient Temperature: -13°F~104°F
- :: Dimmable: 0~10V dimmable
- :: CRI:>80
- :: Power Factor:>0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | |
| SCX4-IP66-JUMP-12IN | - :: SCX4-IP66 12In Ac Jump Cable With Male And Female Wet Loc. Connector
| | SPEC |
 | IGL-10W-RGBW | - :: Stainless Steel Cover/Aluminum Housing/SS Housing/PVC Sleeve
- :: LED: COB Technology (Dimmable)
- :: Lens: Glass
- :: Wattage: 10W
- :: Lumens: 620LM
- :: Voltage: 12V AC/DC
- :: Beam Angle: 90°
- :: Color Temp: RGB+W (W=3000K Warm White)
- :: 1-year warranty
- :: IP Rating: IP67, Wet Location
| | SPEC |
 | SCX4-IP66-CB | - :: SCX4-IP66 Coupling Bracket
| | SPEC |
 | ULR-IN-98F-HO-35K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 4.4W per ft.
- :: Max Run: 20ft.
- :: Efficacy: 75~79LM/W per ft.
- :: Cutting increment: Every 4 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 5/8” on center, 19 per foot,0.23wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 310~350LM per ft.
- :: Color temperature: 3500K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | SPEC |
| ULR-IN-98F-XHO-35K | - :: Voltage: 24VDC (LED driver required)
- :: Wattage: 8.8W per ft.
- :: Max Run: 11ft.
- :: Efficacy: 70~79LM/W per ft.
- :: Cutting increment: Every 2 inches
- :: 3M double sided tape(9474LE) is preinstalled
- :: Includes 1 female ribbon-to-power supply connector(Prewired) and 1 male plug for connection to nextribbon (Prewired)
- :: IP rating: IP20
- :: Dimming: Dimmable using a magnetic driver
- :: LED: SMD2835 chip spaced 1/3” on center, 37 per foot,0.23 wats each chip
- :: LED Type: SMD2835
- :: Total lumens: 620~700LM per ft.
- :: Color temperature: 3500K
- :: Color rendering index: 90
- :: Beam Angle: 120º
| | BRCH SPEC |
 | IGL-1W-TRM-AL-RAZ | - :: Trims for 1W In-Ground Fixtures
| | |
| ULR-IN-98F-HO-COB-50K | - :: LED: COB480 Dotless Technology
- :: Length: 98.4FT
- :: Width: 0.39IN
- :: LEDs/Ft: 150
- :: CCT: 5000K
- :: Dimmable using a magnetic driver
- :: Cutting increment: Every 4 inches
- :: Working voltage: 24V DC (LED driver required)
- :: Power: 3 watts per foot
- :: Lumens: 340LM/FT
- :: CRI: 90
- :: Max run: 20'
- :: 120° beam angle
- :: 3M double sided tape is preinstalled
- :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
- :: IP20
- :: 5-year warranty
| | SPEC BRCH |
 | SCX6-IC-MCTP | - :: Dimmable: 0~10V dimmable
- :: CRI:>80
- :: Power Factor:>0.95
- :: Efficacy
- :: 110LM/W
- :: IP Rating
- :: IP54
- :: Life Span
- :: 50,000 hours
- :: Housing
- :: White, Aluminum
- :: Frosted Polycarbonate
- :: Lumens: 1050-2100LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
| | |
 | SCX4-IC-MCT4 | - :: Low Profile Modern Design
- :: Lumens: 629LM/726LM/787LM/854LM
- :: Color Temperature: 3000K/3500K/4000K/5000K
- :: Aluminum Housing with Matte White Finish
- :: Custom Colors Available
- :: Lens Snaps into Housing
- :: Lens Type: Polished Aluminum Louver Lens
- :: Mounting Options: Surface, Suspended, Wall, Recessed
- :: IP Rating: IP54
- :: Dimmable: 0~10V Dimming
- :: Multi-CCT (Selectable Switch Inside Fixture)
- :: Color Rendering Index: CRI ≥ 80
- :: Up Light Option Available
- :: 50,000 Hours Rated Life
- :: 5-Year Warranty
- :: Beam Angle: 104.8°(H) x 100.5°(V)
| | SPEC  IES |
 | SCX-IC-RGBWW | - :: SCX 2.75 in Linear Inside Corner
- :: 3000K/3500K/4000K/5000K
| | SPEC INST |
 | HL6R-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-ratedairtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation
- :: 7-Year Warranty
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | IGL-1W-TRM-AL-RBK | - :: Trims for 1W In-Ground Fixtures
| | |
 | HL6-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation lagging
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-BoxvUL listed for damp location.
- :: UL listed for Air Tight construction
- :: Meet Title24 requirement
- :: ETLus
| | SPEC INST |
 | ELB-2048-IP65 | | | |
 | HL6S-ICAT | - :: Four remodel clips secure the housing and accommodate 1/2” and 5/8” ceiling materials.
- :: Single-wall painted steel housing with gasket for IC-rated airtight installation in insulated ceilings
- :: Airtight to prevent heated airflow diffusion
- :: IC-rated; can be directly installed on ceiling insulation lagging
- :: Listed for through-branch circuit wiring
- :: Contains nine 8-3/5” knockouts and four Romex pry-outs with strain relief
- :: Ground wire provided in J-box
- :: Three quick connectors provided on J-Box
- :: UL listed for damp location.
- :: UL listed for Air Tight construction
| | SPEC INST |
 | IGL-1W-TRM-AL-RWH | - :: Trims for 1W In-Ground Fixtures
| | |
 | IGL-1W-TRM-AL-SCP | - :: Trims for 1W In-Ground Fixtures
| | |
 | IGL-1W-TRM-SS-1WY | | | |
 | IGL-1W-TRM-SS-2WY | - :: Trims for 1W In-Ground Fixtures
| | |
 | IGL-1W-TRM-SS-SQSQ | - :: Trims for 1W In-Ground Fixtures
| | |
 | IGL-3W-TRM-AL-RBN | - :: Trims for 3W In-Ground Fixtures
| | |
 | IGL-3W-TRM-AL-RLBN | - :: Trims for 3W In-Ground Fixtures
| | |
 | IGL-3W-TRM-SS-1WY | | | |
 | IGL-3W-TRM-SS-2WY | - :: Trims for 3W In-Ground Fixtures
| | |
 | IGL-3W-TRM-SS-R | | | |
| SCX-IC-40K | - :: Lumens: 787LM
- :: Color Temperatures: 4000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
| SCX-IC-50K | - :: Lumens: 854LM
- :: Color Temperatures: 5000K
- :: CRI: >80
- :: Power Factor: >0.95
- :: Efficacy: 110LM/W
- :: IP Rating: IP54
- :: Life Span: 50,000 hours
- :: Housing: White, Aluminum
- :: Lens: Frosted Polycarbonate
| | SPEC |
 | ELB-CW-27W-MV-IP66 | | | |
 1 RESIZED.jpg?alt=media)
 1 RESIZED.jpg?alt=media)
 RESIZED.jpg?alt=media)
