EXPR-SERIES
EXPR - Round Hazardous Location Flood/Highbay Lights
Technical Specs
- :: Voltage: 120-277V AC 60Hz
- :: Wattage: 30W-150W
- :: Power Factor: >0.90
- :: THD: ≤20%
- :: Efficacy: 146-150LPW
- :: Aluminum Alloy Housing
- :: Gray Finish
- :: 3/4" Threaded KO On Top
- :: Cord Type: 3' SJTW 18/3 AWG Cable
- :: Operating Temperature: -40°F to 176°F
- :: IP Rating: IP66, Suitable for Wet Locations
- :: 7-Year Warranty
- :: Lens: Clear Glass
- :: LED: Samsung/SMD 2835 (0.5W)
- :: Total Lumens: 4380LM-22500LM
- :: Color Temperatures: 5000K
- :: Color Rendering Index: CRI ≥ 84
- :: Rated Life: 70,000 Hrs
- :: Beam Angle: 100°
Applications
- :: Warehouse, Factory And Workshops;
- :: Petroleum and Petrochemical Area, And Gas Stations
- :: Power, Railway, Ship Port, Public Security, Fire Protection And Other Fields
- Variations
- Q & A (0)
| Product Name | Lumens | Color Temp | Watts | Description | Voltage | Features | ||
|---|---|---|---|---|---|---|---|---|
EXPR-30W-50K  SPEC | 4380LM | 5000K | 30W | 120-277V AC 60Hz |    | |||
EXPR-60W-50K SPEC | 8580LM | 5000K | 60W | 120-277V AC 60Hz | | |||
EXPR-100W-50K SPEC | 15300LM | 5000K | 100W | 120-277V AC 60Hz | | |||
EXPR-150W-50K SPEC | 23250LM | 5000K | 150W | 120-277V AC 60Hz | | |||
| 22500LM | 5000K | 150W | 480V AC 60Hz | | ||||
EXPR-30-60W-WGF SPEC | 30W-60W | Flat Wire Guard for EXPR 30W to 60W | ||||||
| 100W-150W | Flat Wire Guard for EXPR 100W to 150W | |||||||
EXPR-30-60W-LD SPEC | 30W-60W | Dome Lens for EXPR 30W to 60W | ||||||
EXPR-100-150W-LD SPEC | 100W-150W | Dome Lens for EXPR 100W to 150W | ||||||
EXPR-30-60W-WGD SPEC | 30W-60W | Dome Wire Guard for EXPR 30W to 60W | ||||||
| 100W-150W | Dome Wire Guard for EXPR 100W to 150W | |||||||
EXPR-30-60W-LU SPEC | 30W-60W | U-shape Jelly-Jar Lens for EXPR 30W to 60W | ||||||
EXPR-30-60W-WGU SPEC | 30W-60W | U-Shape Jelly-Jar Wire Guard for EXPR 30W to 60W |
ACCESSORIES
| Product Name | Watts | Description | |||
|---|---|---|---|---|---|
 EXPR-30-60W-WGF SPEC | 30W-60W | Flat Wire Guard for EXPR 30W to 60W | |||
| 100W-150W | Flat Wire Guard for EXPR 100W to 150W | ||||
 EXPR-30-60W-LD SPEC | 30W-60W | Dome Lens for EXPR 30W to 60W | |||
EXPR-100-150W-LD SPEC | 100W-150W | Dome Lens for EXPR 100W to 150W | |||
 EXPR-30-60W-LU SPEC | 30W-60W | U-shape Jelly-Jar Lens for EXPR 30W to 60W | |||
 EXPR-30-60W-WGU SPEC | 30W-60W | U-Shape Jelly-Jar Wire Guard for EXPR 30W to 60W |
