FINAL PRODUCTION
LHB-SERIES LED High Bays
Technical Specs
- :: Die-cast aluminum housing with ribbed polycarbonate reflector (aluminum for 220W)
- :: LED: LUMILEDs
- :: Voltage: 120~277V; 60Hz AC
- :: CRI: 80
- :: Power Factor: 95%
- :: L70 design life (50,000 hours)
- :: Operating Temp: -4°F to 122°F
- :: Suitable for Damp Locations
- :: Dimmable in meanwell drivers 150W and 220W
Applications
- :: Ideal for general warehouse lighting, loading docks, storage areas, supermarkets. The polycarbonate lens provide 360o illumination combined with crisp, directional, bright 5000K light that will make mechandise clearly visible and eye-catching.
- Variations
- Q & A (1)
| Product Name | Lumens | Color Temp | Replacement Range | Watts | Dimensions | Description | Features | |
|---|---|---|---|---|---|---|---|---|
.jpg%3Falt%3Dmedia&w=3840&q=75&dpl=dpl_ECD4au1LZVkkxuMD5nyZbM3eFfWU) LHB-50-CW  BRCH | 5800LM | 5000K | 100~175 MH | 50W | 12"(Diameter) x 12"(H)" |       | ||
 LHB-100-CW SPEC BRCH SPD | 11800LM | 5000K | 250~320 MH | 100W | 16"(Diameter) x 16"(H)" | | ||
LHB-100-NW SPEC BRCH SPD | 11500LM | 4000K | 250~320 MH | 100W | 16"(Diameter) x 16"(H)" | | ||
LHB-150-CW SPEC BRCH INST | 17100LM | 5000K | 340~400 MH | 150W | 16"(Diameter) x 16"(H)" | | ||
.jpg%3Falt%3Dmedia&w=3840&q=75&dpl=dpl_ECD4au1LZVkkxuMD5nyZbM3eFfWU) LHB-220-CW SPEC BRCH SPD | 27000LM | 5000K | 350~400 MH | 220W | 16"(Diameter) x 10"(H)" | | ||
LHB-220-NW SPEC BRCH SPD | 26000LM | 4000K | 350~400 MH | 220W | 16"(Diameter) x 10"(H)" | | ||
 LHB-BRKT-150 BRCH | Optional surface mount bracket for 150W | |
