PC-1H-SERIES PC-1H Series 277V Dusk-to-Dawn Photocell Light Switches
Technical Specs
- :: Dusk-to-dawn photocell light switch
- :: Input voltage 277V AC (208-277VAC range), 50/60Hz
- :: Rated load 1800W tungsten / 1100VA ballast
- :: Power consumption 1.5VA
- :: On/Off levels 10~20 Lx On (dusk) / 30~60 Lx Off (dawn)
- :: Reaction time 30 seconds
- :: Detection angle 180°
- :: Stem size 1/2-inch NPT
- :: Wire length 6-inch, AWG #16
- :: Operating temperature -40°F to 158°F
- :: IP54 rated
- :: UL Listed (E495588); conforms to UL 773A
Applications
- :: The Westgate PC-1H Series automatically turns lighting on at dusk and off at dawn, taking the guesswork out of outdoor lighting control on higher-voltage circuits. Weatherproof and built for the elements, it is the reliable choice for all outdoor lights, from building exteriors and parking areas to walkways, signage, and security lighting.
- Variations
- Q & A (0)
| Product Name | Watts | Description | Voltage | Features | |
|---|---|---|---|---|---|
 PC-1H  SPEC | 1.5VA power consumption; switches up to 1800W tungsten / 1100VA ballast | 277V Dusk-to-Dawn Photocell Light Switch | 277V AC |  |
