TRM-SERIES TRM Series Micro LED Track Heads
Technical Specs
- :: Voltage: 120VAC, 60 Hz
- :: Wattage: 4W (TRM-100) or 6W (TRM-125)
- :: Lumen output: 300 lumens (4W) or 400 lumens (6W)
- :: Efficacy: 75 LM/W (4W); 66 LM/W (6W)
- :: Color temperature: 2700K or 3000K models
- :: CRI: 90
- :: R9: 50
- :: Beam angle: 36°
- :: SDCM: <3
- :: Dimming: TRIAC / ELV, 2% to 100% range, CCR dimming method
- :: Power factor: >0.92
- :: THD: <15%
- :: Protection: Over-temperature and over-voltage
- :: Profile: Cylindrical, 1-inch (TRM-100) or 1.25-inch (TRM-125) diameter
- :: Overall height with H-type adapter: 7-1/2-inch
- :: Adjustment: 350° horizontal rotation, 90° vertical aiming
- :: Track adapter: H-type 3-wire, 1-circuit; compatible with Halo H-type track systems and Westgate H-type track accessories
- :: Finish: Black or white
- :: Installation: Ceiling track
- :: Ingress protection: IP20
- :: Impact rating: IK08
- :: Operating temperature: 14°F to 95°F (-10°C to 35°C)
- :: Warranty: 5-Year
- :: Certifications: ETL Listed, FCC
Applications
- :: The Westgate TRM Series packs precise, directional accent light into a minimal cylindrical profile that stays discreet on the track.
- :: Ideal for accent, display, retail, gallery, hospitality, and residential lighting where compact, directional illumination is required.
- :: Its 350° rotation and 90° tilt let each head be aimed exactly where light is needed.
- Variations
- Q & A (0)
| Product Name | Housing Finish | Lumens | Color Temp | Watts | Voltage | Features | |
|---|---|---|---|---|---|---|---|
 TRM-100-4W-27K-36D-BK  SPEC INST | Black | 300 | 2700K | 4W | 120VAC |   | |
 TRM-100-4W-27K-36D-WH SPEC INST | White | 300 | 2700K | 4W | 120VAC | | |
TRM-100-4W-30K-36D-BK SPEC INST | Black | 300 | 3000K | 4W | 120VAC | | |
TRM-100-4W-30K-36D-WH SPEC INST | White | 300 | 3000K | 4W | 120VAC | | |
TRM-125-6W-27K-36D-BK SPEC INST | Black | 400 | 2700K | 6W | 120VAC | | |
TRM-125-6W-27K-36D-WH SPEC INST | White | 400LM | 2700K | 6W | 120VAC | | |
TRM-125-6W-30K-36D-BK SPEC INST | Black | 400 | 3000K | 6W | 120VAC | | |
TRM-125-6W-30K-36D-WH SPEC INST | White | 400LM | 3000K | 6W | 120VAC | |
ACCESSORIES
| Product Name | Housing Finish | Description | ||
|---|---|---|---|---|
 TR-FLEXC-WH SPEC | White | White Flexible Connector | ||
 TR-EC-BK SPEC | Black | 3-Wire Track End Cap | ||
TR-EC-WH SPEC | White | 3-Wire Track End Cap | ||
 TR-FLEXC-BK SPEC | Black | 3-Wire Track Flex Connector | ||
 TR-LC-BK SPEC | Black | 3-Wire Track L Connector | ||
 TR-LC-WH SPEC | White | 3-Wire Track L Connector | ||
 TR-LE-BK SPEC | Black | 3-Wire Track Live End Connector | ||
 TR-XC-BK SPEC | Black | 3-Wire Track X Connector | ||
 TR-XC-WH SPEC | White | 3-Wire Track X Connector | ||
 TR-MC-BK SPEC | Black | 3-Wire Track Mini Connector | ||
 TR-MC-WH SPEC | White | 3-Wire Track Mini Connector | ||
 TR-MONC-BK SPEC | Black | 3-Wire Track Mini Connector | ||
 TR-MONC-WH SPEC | White | 3-Wire Track Mono Canopy | ||
 TR-SC-BK SPEC | Black | 3-Wire Track Straight Connector | ||
 TR-SC-WH SPEC | White | 3-Wire Track Straight Connector | ||
 TR-TC-BK SPEC | Black | 3-Wire Track T Connector | ||
 TR-TC-WH SPEC | White | 3-Wire Track T Connector | ||
 TR-FC-BK SPEC | Black | 3-Wire Track Floating Canopy | ||
 TR-FC-WH SPEC | White | 3-Wire Track Floating Canopy | ||
 TR-2FT-BK SPEC | Black | 2Ft 3-Wire Track | ||
TR-2FT-WH SPEC | White | 2Ft 3-Wire Track | ||
TR-4FT-BK SPEC | Black | 4Ft 3-Wire Track | ||
TR-4FT-WH SPEC | White | 4Ft 3-Wire Track | ||
TR-6FT-BK SPEC | Black | 6Ft 3-Wire Track | ||
TR-6FT-WH SPEC | White | 6Ft 3-Wire Track | ||
TR-8FT-BK SPEC | Black | 8Ft 3-Wire Track | ||
TR-8FT-WH SPEC | White | 8Ft 3-Wire Track | ||
 TR-JBEF-BK SPEC | Black | 3-Wire Track J-Box End Feed Kit | ||
 TR-JBEF-WH SPEC | White | 3-Wire Track J-Box End Feed Kit | ||
 TR-CCON-BK SPEC | Black | 3-Wire Track Conduit Connector | ||
 TR-CCON-WH SPEC | White | 3-Wire Track Conduit Connector | ||
 TR-EXTCON-BK SPEC | Black | 3-Wire Track To Track Extension Connector | ||
 TR-EXTCON-WH SPEC | White | 3-Wire Track To Track Extension Connector | ||
TR-LE-WH SPEC | White | 3-Wire Track Live End |
