ULR-IN-BK-SERIES

UL-Listed 24V Indoor High Output LED Ribbon

Technical Specs

  • :: LED: SMD2835 chip spaced 5/8” on center, 19 LED per foot, 0.24 watts each chip
  • :: Dimmable using a magnetic driver
  • :: Cutting increment: Every 4 inches
  • :: Working voltage: 24V DC (LED driver required)
  • :: Power: 4.4 watts per foot
  • :: Lumens: 350 lumens per foot, 18.5 LM per LED
  • :: CRI: 90
  • :: Max run: 20’
  • :: 120º beam angle
  • :: 3M double sided tape is preinstalled
  • :: Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
  • :: Operating temperature: -4°F - 104°F
  • :: IP20
  • :: 5-year warranty

Applications

  • :: Ideal for undercabinet, soffit, display cases and toe kick lighting.
image description
  • Variations
  • Q & A

Product NameLumens Per FtWatts Per FtLEDs Per FtWidthMax RunReel LengthLED TypeColor TempFeatures
ULR-IN-16F-HO-27K-BK
image description

SPEC

image description

IES

image description

CAT

image description

LUX

image description

MANU

310LM4.4W190.4"20FT16.4FTSMD28352700K
image description
image description
ULR-IN-16F-HO-30K-BK
image description

SPEC

image description

IES

image description

CAT

image description

LUX

image description

MANU

310LM4.4W190.4"20FT16.4FTSMD28353000K
image description
image description
ULR-IN-16F-HO-40K-BK
image description

SPEC

image description

IES

image description

CAT

image description

LUX

image description

MANU

330LM4.4W190.4"20FT16.4FTSMD28354000K
image description
image description
ULR-IN-16F-HO-50K-BK
image description

SPEC

image description

IES

image description

CAT

image description

LUX

image description

MANU

350LM4.4W190.4"20FT16.4FTSMD28355000K
