WAX-SERIES WAX Series Modern Adjustable LED Wall Pack, Power & CCT Selectable

Technical Specs

  • :: Wattage: 20W / 30W / 40W, 50W / 65W / 80W, or 90W / 105W / 120W selectable
  • :: Lumens: up to 5,600lm, 11,200lm, or 16,800lm
  • :: Voltage: 120-277VAC, 60Hz
  • :: Efficacy: 140lm/W
  • :: CCT: 3000K / 4000K / 5000K selectable
  • :: CRI ≥80
  • :: Beam Angle: 127° (H) x 85° (V)
  • :: BUG Rating: B2-U0-G1 (40W), B3-U0-G2 (80W), B3-U0-G3 (120W)
  • :: Dimming: 0-10V
  • :: PF >0.90
  • :: THD: <20%
  • :: DC button photocell with ON/OFF switch included
  • :: Light head adjusts from 0° to 90°, full cutoff
  • :: Die-cast aluminum housing; Dark Bronze, Black, Silver, or White
  • :: Anti-UV, fire-resistant, shatterproof PC lens
  • :: Dimensions: 14" (L) x 5 1/4" (W) x 12 7/8" (H)
  • :: IP65, wet location
  • :: Operating Temp: -40°F to 113°F
  • :: Rated Life: 70,000 hours
  • :: 7-year warranty
  • :: cULus Listed

Applications

  • :: The Westgate WAX Series is a modern adjustable LED wall pack for entrances, doorways, alleys, courtyards, loading docks, building perimeters, parking areas, hotels, and general site lighting. Wattage and color temperature are set with switches inside the fixture, and the light head adjusts from 0° to 90° to aim light exactly where it is needed. Every model includes a DC button photocell with an ON/OFF switch and works well with motion sensors and other instant on/off controls. Three power ranges and Dark Bronze, Black, Silver, or White finishes cover everything from small doorways to large building facades.
  • Variations
  • Q & A (0)

Product NameHousing FinishLumensColor TempWattsVoltageFinishFactory-Installed OptionsFeatures
40W Max Dark Bronze Adjustable LED Wall Pack, Power & CCT Selectable
WAX-20-40W-MCTP
SPEC document

SPEC

INST document

INST

IES document

IES

2,800lm/4,200lm/5,600lm3000K/4000K/5000K20W/30W/40W 120-277VACDark Bronze
  • option-icon

    OPT-EM-WAX-40

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
2,800lm/4,200lm/5,600lm3000K/4000K/5000K20W/30W/40W 120-277VACWhite
  • option-icon

    OPT-EM-WAX-40

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
2,800lm/4,200lm/5,600lm3000K/4000K/5000K20W/30W/40W 120-277VACBlack
  • option-icon

    OPT-EM-WAX-40

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-TRS-T20

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
80W Max Dark Bronze Adjustable LED Wall Pack, Power & CCT Selectable
WAX-50-80W-MCTP
SPEC document

SPEC

INST document

INST

IES document

IES

Dark Bronze7,000lm/9,100lm/11,200lm3000K/4000K/5000K50W/65W/80W120-277VAC
  • option-icon

    OPT-EM-WAX-80

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
7,000lm/9,100lm/11,200lm3000K/4000K/5000K50W/65W/80W120-277VACWhite
  • option-icon

    OPT-EM-WAX-80

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
7,000lm/9,100lm/11,200lm3000K/4000K/5000K50W/65W/80W120-277VACBlack
  • option-icon

    OPT-EM-WAX-80

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
IP65
Where to Buy
120W Max Dark Bronze Adjustable LED Wall Pack, Power & CCT Selectable
WAX-90-120W-MCTP
SPEC document

SPEC

IES document

IES

INST document

INST

12,600lm/14,700lm/16,800lm3000K/4000K/5000K90W/105W/120W120-277VACDark Bronze
  • option-icon

    OPT-EM-WAX-120

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
12,600lm/14,700lm/16,800lm3000K/4000K/5000K90W/105W/120W120-277VACWhite
  • option-icon

    OPT-EM-WAX-120

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
12,600lm/14,700lm/16,800lm3000K/4000K/5000K90W/105W/120W120-277VACBlack
  • option-icon

    OPT-EM-WAX-120

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
2,800lm/4,200lm/5,600lm3000K/4000K/5000K20W/30W/40W120-277VACSilver
  • option-icon

    OPT-EM-WAX-40

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
7,000lm/9,100lm/11,200lm3000K/4000K/5000K50W/65W/80W 120-277VACSilver
  • option-icon

    OPT-EM-WAX-80

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy
12,600lm/14,700lm/16,800lm3000K/4000K/5000K90W/105W/120W 120-277VACSilver
  • option-icon

    OPT-EM-WAX-120

  • option-icon

    OPT-SEN-3MRLV-5

  • option-icon

    OPT-SEN-NLS-WAX

  • option-icon

    OPT-SEN-KEILTON-WAX

  • option-icon

    OPT-PC-B

  • option-icon

    OPT-WP-480V

  • option-icon

    OPT-CLR-85(BK/GR/SR/WH)

  • option-icon

    OPT-CLR-MC

  • option-icon

    OPT-TRS-T20

cUL
Dimming 0-10V
Wet Location
MCTP
Where to Buy

ACCESSORIES

Product NameDescription
Remote Control For WEC-3MR-4 & WEC-3MR-3
Where to Buy
