WPV-SERIES WPV Series Vandal-Proof LED Outdoor Wall and Ceiling Light, CCT Selectable

Technical Specs

:: Input Voltage: 120VAC (WPV, WPV2, WPV3); 120-277VAC (WPV4)
:: Wattage: 12W or 15W
:: Dimming: TRIAC (WPV4 adds 0-10V at 120-277VAC)
:: Lumens: 900lm to 1,100lm
:: Efficacy: 73 to 80lm/W
:: CCT: 3000K / 4000K / 5000K, selectable
:: CRI: ≥70 (WPV); 80 (WPV2, WPV3, WPV4)
:: Beam Angle: 110° x 130° (WPV); 220° (WPV2, WPV3, WPV4)
:: Housing: Steel, White finish; vandal resistant design
:: Lens: Shatterproof PC (WPV); clear striped-pattern sealed diffuser (WPV2, WPV3, WPV4)
:: Mounting: Surface wall mount (WPV, WPV2, WPV3); surface ceiling mount (WPV4)
:: Location: Wet location
:: Rated Life: 70,000 hours
:: Warranty: 7-year warranty
:: Certifications: ETL and cETL Listed

:: The Westgate WPV Series is a family of vandal-proof LED fixtures built for exposed, high-traffic exterior locations where durability matters as much as light. Steel construction, shatterproof or sealed diffusers, and tamper-resistant hardware protect each fixture, while selectable color temperature lets one model match the look of each site. It is ideal for general site lighting, entrances, doorways, alleys, loading docks, walkways, stairwells, corridors, breezeways, and building perimeters. Choose the original WPV wall pack, the compact WPV2 or slim low-profile WPV3 wall lights, or the square WPV4 ceiling light for canopies and covered areas, which adds 120-277VAC input and 0-10V dimming.

Product Name	Housing Finish	Lumens	Color Temp	Watts	Voltage	Factory-Installed Options
WPV-12W-MCT-DT SPEC INST IES	White	960lm	3000K/4000K/5000K	12W	120VAC, 60Hz	OPT-SEN-3MRLV-5 OPT-EM-WMV OPT-TRS-T20 OPT-CLR-70(BK/GR/SR/WH) OPT-CLR-70MC	Where to Buy
WPV2-12W-MCT-DT SPEC	White	900lm	3000K/4000K/5000K	12W	120VAC, 50/60Hz	OPT-EM-WMV	Where to Buy
WPV3-15W-MCT-DT SPEC	White	1,100lm	3000K/4000K/5000K	15W	120VAC, 50/60Hz	OPT-EM-WMV	Where to Buy
WPV4-15W-MCT-DD SPEC	White	1,100lm	3000K/4000K/5000K	15W	120-277VAC, 50/60Hz	OPT-EM-WMV	Where to Buy
