:: Type: G5 modular LED bollard head (shaft sold separately)
:: Head: Flat top with cone reflector and frosted lens
:: Wattage: 8W/13W/18W/25W, selectable (factory set to 25W)
:: Lumens: 920lm/1,495lm/2,070lm/2,875lm
:: Efficacy: 115lm/W
:: CCT: 3000K/4000K/5000K, selectable (factory set to 5000K)
:: CRI ≥70
:: Voltage: 120-277VAC
:: PF >0.9
:: Beam Angle: 360°
:: BUG: B1-U3-G1
:: Dimensions (as drawn): 42" (H) or 18 3/4" (H) assembled, Ø8" head, Ø5 1/4" shaft
:: Mounting: Anchor bolts and mounting accessories included (7 1/2" long)
:: Housing: Corrosion-resistant aluminum, Bronze finish
:: IP66, wet locations
:: Operating Temperature: -22°F to 113°F
:: Rated Life: 70,000 hours
:: 7-year warranty

:: The Westgate BOL-G5-101-MCTP-BR is a G5 modern modular LED bollard head for walkways, entrance ways, drives, plazas, parks, and other small-area outdoor spaces where low mounting heights are desirable. Its Ø8" flat top with a cone reflector and frosted lens spreads soft, even light in a full 360° pattern, the higher-output head in the G5 line for walkways, plazas, and entrances. Wattage (8W, 13W, 18W, or 25W) and color temperature (3000K, 4000K, or 5000K) are selectable with switches inside the fixture, delivering up to 2,875lm. Pair the head with a 14" or 33" shaft to set the bollard height, and anchor bolts are included. The corrosion-resistant aluminum housing is IP66 rated for wet locations. This model features a Bronze finish, and the same fixture is also available in Black. Backed by a 7-year warranty.

No questions posted yet for this product!

ACCESSORIES

Product Name	Description	Finish
BOL-G5-SHAFT-14-BR SPEC INST	G5 Bollard Shaft 14 Inch, Bronze	Bronze	Where to Buy
BOL-G5-SHAFT-33-BR SPEC INST	G5 Bollard Shaft 33 Inch, Bronze	Bronze	Where to Buy
BOL-G5-ABK-R SPEC INST	G5 Bollard Round Anchor Bolts & Mounting Plate		Where to Buy
