CMC6-RGBW-BK 6" CMC RGBW Cylinder Lights, Pendant or Surface Mount, 20W
Technical Specs
- :: Voltage: 120-277V
- :: Power Factor: >0.90
- :: THD: <20%
- :: Wattage: 20W
- :: Efficacy: 60 LPW
- :: Aluminum Housing & Glass Lens
- :: Suspension Cable & Canopy Set Accessories Available
- :: Universal Swivel w/ Rod Kit Accessories Available Ambient
- :: Operating Temperature: -13ºF to 113ºF
- :: Rated Life: 70,000 hrs.
- :: IP Rating: IP40 Suitable for Damp Locations
- :: Color Temperatures: RGBW Selectable Through Phone App
- :: Dimming: (Dual Function) Triac Dimmable at 120V & 0-10V Dimming at 120-277V
- :: Total Lumens: 1200LM Max.
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 120°
Applications
- :: 6’’ Cylinder, Pendant & Ceiling Cylinder Light, Aluminum Cylinder, White Aluminum Housing, Clear Glass Lens
Features
Q & A
No questions posted yet for this product!
ACCESSORIES
| Product Name | Description | Housing Finish | Watts | Lumens | Color Temp | ||
|---|---|---|---|---|---|---|---|
 CMC-OWCC-BK SPEC | 5In Old-Work Recessed Ceiling Canopy With Junction Box For CMC Cylinders | Black | |||||
| Universal Swivel W/ Rod Kit, 18 Or 36 Inches, 5-Wire, White | |||||||
| Universal Swivel W/ Rod Kit, 18 Or 36 Inches, 5-Wire, Black | |||||||
| Universal Swivel W/ Rod Kit, 24 Or 48 Inches, 5-Wire, White | |||||||
| Universal Swivel W/ Rod Kit, 24 Or 48 Inches, 5-Wire, Black | |||||||
| Universal Swivel W/ Rod Kit, 40 Or 80 Or 120 Inches, 5-Wire, White | |||||||
| Universal Swivel W/ Rod Kit, 40 Or 80 Or 120 Inches, 5-Wire, Black | |||||||
 CMC6-TRM-AG SPEC | 6-inch ceiling mount cylinder trim, Anodized Gold (AG) | ||||||
 CMC6-TRM-BN SPEC | 6-inch ceiling mount cylinder trim, Anodized Gold (AG) | ||||||
CMC6-HCDK-AG SPEC | 6-inch cylinder honeycomb diffuser kit, Anodized Gold (AG) | ||||||
 CMC6-HCDK-BK SPEC | 6-inch ceiling mount cylinder honeycomb diffuser kit, Black | ||||||
 TR-PENDKIT-BK SPEC | Pendkit accessory for track and pendant lights | Black | |||||
 TR-PENDKIT-WH SPEC | Pendkit accessory for track and pendant lights | White | |||||
 CMC46-ULK SPEC | Up Light Kit | 5W | 400LM | 3000K/4000K/5000K | |||
 CMC6-WPCK-WH SPEC | CMC6 Weatherproof Conversion Kit For Cord Or Down-Rod, White | ||||||
 CMC6-WPCK-BK SPEC | WMC 4in 32mm Acrylic Drop Lens |
