:: Voltage: 120V AC
:: Output Voltage: 36VDC
:: Power Factor: >0.90
:: Wattage: 15W
:: Efficacy: 75 LP
:: Total Harmonic Distortion: ≤15 %
:: 1/4”Thick
:: Up to 9 AWG18 Wires
:: Die-cast Aluminum With White Powder Coat Finish
:: Pot Light Housing is Not Required Even for InsulatedCeiling
:: Junction Box 1” Thick Included With Fixture
:: Type Crated: Approved For Direct Contact WithInsulation
:: Indoor or covered outdoor use only. Direct UV exposure may cause discoloration or material degradation within 1 to 3 years in high-UV environments, coastal, or high altitude areas
:: Maximum Ambient Temperature: -4°F to 104°F
:: Damp Location
:: Multi CCT (Selectable Switch On The Back Of TheDriver )
:: Dimming: Dimmable Down to 10% Using a StandardTRIAC LED Dimmer
:: Lens: 0.125” White Translucent Acrylic
:: Can Rotate After Installation To Align
:: LED: Seoul DOB (Driver On Board) Technology
:: Optics: White Translucent Acrylic
:: Total Lumens: 1125LM
:: Color Temperatures: 2700K/ 3000

:: LED recessed trims have been designed to bea flexible lighting solution for new constructioapplications, Ideal for closets, storage areas, attics,corridors, or general lighting solutions for residentialand commercial applications
