SCR-18D-MCTP5-D 18-inch 15-35W Round LED Suspended Down Light, MCTP5 Selectable

:: Voltage: 120-277V AC, 50/60Hz
:: Wattage: 15W / 20W / 25W / 30W / 35W (5-Step Selectable)
:: Power Factor: >0.98
:: Total Harmonic Distortion: <=19%
:: Efficacy: 100 LM/W
:: Dimming: 0-10V Dimming
:: Total Lumens: 1,500 / 2,000 / 2,500 / 3,000 / 3,500 LM (Max 3,500 LM)
:: CCT Selectable: 2700K / 3000K / 3500K / 4000K / 5000K
:: MCTP5: Multi Color Temperature and Multi Power, 5-Step Selectable via Switches Inside Canopy
:: Color Rendering Index: CRI >=80
:: Beam Angle: 114-degree (H) x 114-degree (V)
:: Housing: Aluminum with Sandy White Finish
:: Lens: Opal Polycarbonate, Direct Down Light
:: Suspension: Three 10FT Adjustable Suspension Cables
:: Diameter: 17.72-inch
:: Fixture Dimensions: 17.72-inch (Dia) x 3.15-inch (H)
:: Canopy Dimensions: 5.12-inch (Dia) x 0.63-inch (H)
:: Operating Temperature: -46-degree F to 104-degree F
:: IP Rating: IP20
:: BUG Rating: B2-U3-G1
:: Rated Life: 50,000 Hours
:: Warranty: 5 Years
:: Certifications: UL Listed

:: The SCR-18D-MCTP5-D is the 18-inch, 15W to 35W member of the SCR Series, a slightly larger compact size for medium conference tables, private offices, boutique retail, and hospitality nooks that need a bit more presence and output than the 16-inch. It shares the series opal polycarbonate direct down light, three-cable suspension, and canopy-mounted MCTP5 wattage and CCT selection. What sets this SKU apart is its 18-inch diameter and 15W to 35W range, a step up from the 16-inch. An optional uplight kit adds an indirect upward glow.

No questions posted yet for this product!

OPTIONS

OPT-SEN-SCR

OPT-EM-SCR
