SCX4-IP66-SUS-4FT-10-20W-MCTP-50LPF-BK Black 4 ft 10W-20W IP66 Wet Location Suspended LED Linear Light
Technical Specs
- :: Input Voltage: 120-277VAC, 50/60Hz
- :: Wattage: 10W / 15W / 20W, field selectable
- :: Power Factor: >0.95
- :: THD: ≤19%
- :: Dimming: 0-10V
- :: Lumens: 1,300 / 1,950 / 2,600 LM
- :: Efficacy: 130 LPW
- :: CCT: 3500K / 4000K / 5000K, field selectable
- :: CRI: ≥80
- :: Beam Angle: 105° (H) x 103.7° (V)
- :: BUG Rating: B2-U3-G1
- :: Lens: Opal polycarbonate, direct downlight
- :: Wiring: Waterproof male and female connectors pre-installed on top near both ends; power cord not included
- :: Housing: Aluminum, Black finish, low-profile design
- :: Mounting: Suspended (rod kit or aircraft cable, sold separately) or wall; wall mounting kit included
- :: Dimensions: 47.5-inch L x 4.2-inch W x 3.5-inch H
- :: IP Rating: IP66, Wet Location
- :: Operating Temp: -22°F to 104°F
- :: Rated Life: 50,000 hours
- :: Warranty: 5 years
- :: Certifications: UL Listed
Applications
- :: The Westgate SCX4-IP66-SUS 4 ft low-output linear light pairs a sleek Black finish with the protection of an IP66 wet location rating. It is ideal for restaurants, hotels, lobbies, retail locations, corridors, and other spaces with exposed or dark ceilings where softer, lower light levels and a bold architectural look are preferred, including areas exposed to moisture. Pre-installed waterproof connectors make it easy to power fixtures and link them into continuous runs, and it can be suspended by rod kit or aircraft cable or wall mounted with the included kit. Compared with the standard 40W-80W model, it delivers lower output for accent and ambient lighting, and an 8 ft Black low-output model is also available.
Features
Q & A
No questions posted yet for this product!
ACCESSORIES
| Product Name | Description | ||
|---|---|---|---|
| 6 ft AC Power Pigtail with Female Wet Location Connector | |||
| 10 ft AC Power Pigtail with Female Wet Location Connector | |||
| 6-Inch AC Jump Cable with Male and Female Wet Location Connectors | |||
| 12-Inch AC Jump Cable with Male and Female Wet Location Connectors | |||
 SCX4-IP66-CB SPEC | Coupling Bracket for IP66 Linear Lights | ||
| 18-Inch Stainless Steel Suspension Rod Kit for IP66 Linear Lights | |||
| 24-Inch Stainless Steel Suspension Rod Kit for IP66 Linear Lights | |||
 SCX4-IP66-SCBK SPEC | Aircraft Cable Suspension Bracket Set for IP66 Linear Lights | ||
 SCL-GS220 SPEC | Heavy-Duty Adjustable 5/64” 20 Ft. Suspension Kit with Loop Gripper & Hooks | ||
SCL-GS210 SPEC | Heavy-Duty Adjustable 5/64" 10ft. Suspension Kit with Loop Gripper & Hook | ||
 SCL-ASC-500FT SPEC | 1/16-inch 500FT Roll Steel Aircraft Suspension Cable | ||
 SCL-6FT-SJTW18/5 SPEC | White 6FT SJTW 18 AWG 5-Conductor Suspension Power Cord | ||
| Heavy-Duty Auxiliary Hook for up to 1/16" Aircraft Cables with Cable Adjustment | |||
| Black 12ft. Cord, SJTW 18 AWG 5-Conduct (WH/BK/GN/PU/GY) |
