WEC-2UGW-WIFI Industrial Multi-Signal Input Gateway with WiFi Output

:: Power input: 5V / 2A
:: Wireless protocols: 2.4G Wi-Fi; BT4.2 (Bluetooth); ZigBee
:: Operating temperature: -10-degreeC to 55-degreeC (14-degreeF to 131-degreeF)
:: Operating humidity: 10% to 90% RH, non-condensing
:: Dimensions: 127mm x 131.5mm x 29.3mm (5-inch x 5.18-inch x 1.15-inch)
:: Net weight: 280g (0.62 lb)
:: Connections: network port terminals; DC power connector; 4 antennas (BLE, ZigBee, WiFi, network)
:: Controls/indicators: SET (settings) button; RES (reset) button; power LED; network status LED
:: Package includes: gateway unit, 4 antennas, power adapter, screw pack, instructions

:: The WEC-2UGW-WIFI from Westgate serves as the control hub for connected lighting systems, bridging multiple wireless signal types into a single WiFi-managed network. It lets facilities add devices, group controls, and integrate lighting into broader smart-building and automation scenes without a tangle of separate controllers. Built for industrial and commercial installations, it centralizes device management so operators can monitor and adjust connected fixtures from one place. Reach for the WEC-2UGW-WIFI when a project needs a dependable gateway to tie wireless lighting controls together.
