WMCS-UDL-MCT-BN-DT Brushed Nickel 24W LED Square Wall Cylinder Up/Down Light, 3CCT
Technical Specs
- :: Light Direction: Up/down light
- :: Wattage: 24W (12W per side)
- :: Lumens: 1,920lm
- :: Efficacy: 80lm/W
- :: CCT: 3000K/4000K/5000K, selectable switch on arm
- :: CRI ≥80
- :: Voltage: 120VAC
- :: PF >0.95 / THD: <20%
- :: Dimming: TRIAC (standard TRIAC LED dimmers)
- :: Beam Angle: 45° each side
- :: Dimensions: 4 5/16" (W) x 10 3/16" (H) x 3 9/16" (D)
- :: Housing: Die-cast aluminum and glass, Brushed Nickel finish
- :: Suitable for wet locations
- :: Operating Temperature: -4°F to 104°F
- :: Rated Life: 70,000 hours
- :: 7-year warranty
Applications
- :: The Westgate WMCS-UDL-MCT-BN-DT is a 24W square LED wall cylinder that projects 45° beams both up and down, washing the wall above and below to frame entries, doorways, walkways, stairways, and building facades. As the up/down model in the WMCS Series, it pairs two 12W light engines for 1,920lm total from a compact die-cast aluminum and glass housing rated for wet locations. Three color temperatures (3000K, 4000K, 5000K) are selectable with a sealed switch on the bottom of the arm, and standard TRIAC dimming adds simple control. A button photocell, emergency battery, microwave sensor, and network sensors are available as factory options. This model features a Brushed Nickel finish, and the same fixture is also available in Black, Bronze, and White.
Features
Q & A
No questions posted yet for this product!
ACCESSORIES
| Product Name | Description | ||
|---|---|---|---|
 WEC-8RC SPEC | Remote Control For WEC-3MR-4 & WEC-3MR-3 |
