WSX-20-40W-MCTP-SRK-224 Spec Series Power & CCT - Adjustable X-Gen Seaside Swivel Rod Light, 20W/30W/40W, 30K/40K/50K
Technical Specs
- :: Voltage: 120-277V AC 60Hz
- :: Wattage: 20W/30W/40W
- :: Power Factor: >0.90
- :: Efficacy: 100 LPW
- :: Aluminum Housing And Steel Back Plate
- :: White Glass Lens
- :: Black Finish
- :: Universal Swivel W/ Rod Kit, 24 Or 48 Inches, 5-Wire,Black OR White
- :: 45” Suspended Chain/Cord & Canopy
- :: Operating Temperature: -4ºF to 104ºF
- :: Wet Location
- :: 7-Year Warranty
- :: IP42, Suitable for Outdoor Use
- :: Dimming: Dimming: (Dual Function) Triac Dimmable at 120V & 0-10V Dimming at 120-277V
- :: Total Lumens: 4000LM Max.
- :: Color Temperatures: 3000K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80
- :: Beam Angle: 90° x 110°
- :: Rated life: 70,000 Hrs
Applications
- :: LED Seaside Outdoor Wall Lantern With Aluminum housing & Powder-Coated Finish, Acrylic Diffuser. Ideal For General Site Lighting, Residential Buildings, Doorway, Pathway And Parking Areas
