LSW-SERIES

LSW - LED Non-Cutoff Wall Packs with Photocell

:: Voltage: 120-277VAC 60Hz
:: Wattage: 20W
:: Power Factor: >0.95
:: Efficacy: 100/103/105 LPW
:: Includes Pre-wired Photo Electric Control (Dusk to Dawn Photocell), 120 Volt, Removable
:: Photocell Response Time: Maximum 3 Seconds
:: Back plate: Die-Cast Aluminum with Mounting/Gasket Installed
:: Threaded 1/2” Knockout Provided on Top Section of the Back
:: Polycarbonate Housing & Lens
:: Non-Cutoff Optics Ideal for Maximum Light Distribution
:: Operating Temperature: -4ºF -104ºF
:: Wet Location
:: 7-Year Warranty
:: IP54
:: LED Type/Brand: SMD 3030/ Lumileds LEDs
:: Front: Polycarbonate Lens and Housing
:: Total Lumens: 2000LM/ 2050LM/ 2100LM
:: Color Temperatures: 3000K/4000K/5000K
:: Color Rendering Index: CRI ≥ 80
:: Beam Angle: 90° x 110°
:: Rated life: 70,000 Hrs

:: Ideal for general site lighting, loading docks, doorways, pathways and parking areas.

Product Name	Lumens	Color Temp	Color	Replacement Range	Watts	Dimensions
LSW-22WW-PC SPEC BRCH SPD IES	2000LM	3000K		50~100 MH	20W	11"L x 6-3/4"W x 5-1/8"H
LSW-22NW-PC SPEC SPD BRCH IES	2050LM	4000K		100~125 MH	20W	11"L x 6-3/4"W x 5-1/8"H
LSW-22CW-PC SPEC BRCH SPD IES	2100LM	5000K	White	50~100 MH	20W	11"L x 6-3/4"W x 5-1/8"H
LSW-30WW-PC SPEC BRCH SPD IES	2800LM	3000K/4000K/5000K		100~125 MH	30W	11"L x 6-3/4"W x 5-1/8"H
LSW-30NW-PC SPEC BRCH SPD IES	2800LM	3500K		100~125 MH	30W	11"L x 6-3/4"W x 5-1/8"H
LSW-30CW-PC SPEC BRCH SPD IES	2900LM	5000K		100~125 MH	30W	11"L x 6-3/4"W x 5-1/8"H

ACCESSORIES

Product Name	Lumens	Color Temp	Color	Replacement Range	Watts	Dimensions
LWA-20WW SPEC BRCH IES SPD INST	2000LM	3000K	Bronze	70~100 MH	20W	8" (w) x 9"" (H) x 4.5"" (D)"
