LWPMAX-SERIES
LWPMAX - Max-Feature Cut-Off Wall Pack
Technical Specs
- :: Input Wattage: 20W/30W/40W/60W/80W/100W/120W/150W
- :: Input Voltage: 120-277V AC 50/60Hz
- :: Input current: 0.6A
- :: Power factor: >0.9
- :: Efficacy: 135 LPW
- :: ADC12 Aluminum Heat Sink, Outdoor Powder Coating
- :: Photocell included
- :: Lens: Prismatic Borosilicate Glass Lens
- :: Same Footprint as Traditional HID Wall Packs
- :: Four 1/2” Hubs: 1 top. 1 on Each Side, 1 Rear
- :: Mounting: Wall Mounting
- :: Operating Temperature: -40°F ~ 122°F
- :: IP rating: IP65, Wet Locations
- :: 7-Year Warranty
- :: Multi Color Temperature & Multi Power/Wattage (Switches are inside fixture)
- :: Dimming: 0-10V Dimming
- :: Multi Power & CCT (Switches are inside fixture)
- :: Adjustable throw (Narrow, Medium & Wide)
- :: Total Lumens: 5400LM-20250LM Max.
- :: Color Temperature: 3000K/4000K/5000K
- :: CRI: >70
- :: Lifespan: 70000 Hrs.
Applications
- :: Entrance and courtyard lighting
- :: Industrial and outdoor landscape lighting
- :: Building and hotel applications
- :: Wall lighting and more.
- Variations
- Q & A (0)
| Product Name | Housing Finish | Lumens | Color Temp | Watts | Voltage | Factory-Install Options | Features | |
|---|---|---|---|---|---|---|---|---|
LWPMAX-SM-20-40W-MCTPB-P  SPEC  IES | Bronze | 5400LM Max. | 3000K/4000K/5000K | 20W/30W/40W | 120-277V AC 50/60Hz |
|      | |
LWPMAX-SM-20-40W-MCTPB-P-BK SPEC IES | Black | 5400LM Max. | 3000K/4000K/5000K | 20W/30W/40W | 120-277V AC 50/60Hz |
| | |
LWPMAX-SM-20-40W-MCTPB-P-SIL SPEC IES | Silver | 5400LM Max. | 3000K/4000K/5000K | 20W/30W/40W | 120-277V AC 50/60Hz |
| | |
LWPMAX-MD-40-80W-MCTPB-P SPEC IES | Bronze | 10800LM Max. | 3000K/4000K/5000K | 40W/60W/80W | 120-277V AC 50/60Hz |
| | |
LWPMAX-MD-40-80W-MCTPB-P-BK SPEC IES | Black | 10800LM Max. | 3000K/4000K/5000K | 40W/60W/80W | 120-277V AC 50/60Hz |
| | |
LWPMAX-MD-40-80W-MCTPB-P-SIL SPEC IES | Silver | 10800LM Max. | 3000K/4000K/5000K | 40W/60W/80W | 120-277V AC 50/60Hz |
| | |
LWPMAX-LG-100-150W-MCTPB-P SPEC IES | Bronze | 20250LM Max. | 3000K/4000K/5000K | 100W/120W/150W | 120-277V AC 50/60Hz |
| | |
| Black | 20250LM Max. | 3000K/4000K/5000K | 100W/120W/150W | 120-277V AC 50/60Hz |
| | ||
| Silver | 20250LM Max. | 3000K/4000K/5000K | 100W/120W/150W | 120-277V AC 50/60Hz |
| |
