SPEC SHEET

LWPMAX-SM-20-40W-MCTPB-P-BK

Max-Feature Cut-Off Wall Pack, 20W/30W/40W, 3000K/4000K/5000K

Technical Specs

  • :: Input Wattage: 20W/30W/40W
  • :: Input Voltage: 120-277V AC 50/60Hz
  • :: Input current: 0.6A
  • :: Power factor: >0.9
  • :: Efficacy: 135 LPW
  • :: ADC12 Aluminum Heat Sink, Outdoor Powder Coating
  • :: Photocell included
  • :: Lens: Prismatic Borosilicate Glass Lens
  • :: Same Footprint as Traditional HID Wall Packs
  • :: Four 1/2” Hubs: 1 top. 1 on Each Side, 1 Rear
  • :: Mounting: Wall Mounting
  • :: Operating Temperature: -40°F ~ 122°F
  • :: IP rating: IP65, Wet Locations
  • :: 7-Year Warranty
  • :: Multi Color Temperature & Multi Power/Wattage (Switches are inside fixture)
  • :: Dimming: 0-10V Dimming
  • :: Multi Power & CCT (Switches are inside fixture)
  • :: Adjustable throw (Narrow, Medium & Wide)
  • :: Total Lumens: 5400LM Max.
  • :: Color Temperature: 3000K/4000K/5000K
  • :: CRI: >70
  • :: Lifespan: 70000 Hrs.

Applications

  • :: Entrance and courtyard lighting
  • :: Industrial and outdoor landscape lighting
  • :: Building and hotel applications
  • :: Wall lighting and more.

Features

  • Dimming 0-10V
  • MCTP
  • Wet Location
  • cUL
  • DLC Listed
