SCXCF-SERIES
SCXCF - Full Circle 10ft. Chandelier, Up & Down Ratio Adjustable with Canopy & Cable
Technical Specs
- :: Voltage: 120-277V AC 50/60Hz
- :: Wattage: 20W-100W
- :: LPW: 100 LM/W
- :: Aluminum Housing, White and Black Finish
- :: Three 10FT Adjustable Suspension Cables
- :: Opal Polycarbonate Lens - Direct and Indirect Light
- :: Operating Temperature: -46°F to 104°F
- :: IP Rating: IP20
- :: 5-Year Warranty
- :: Dimmable: 0~10V Dimming
- :: MCTP: Multi Color Temperature and Power (Selectable, The Switches Are Inside The Canopy)
- :: Total Lumens: 4000LM-10000LM Max.
- :: Color Temperatures: 3000K/3500K/4000K/5000K
- :: Color Rendering Index: CRI ≥ 80,90 Optional
- :: Beam Angle: 114°(H) x 114°(V)
- :: 50,000 Hours Rated Life
Applications
- :: Ideal For Office ,Architectural Lighting And Create Different Visual Experience.
- Variations
- Q & A (0)
| Product Name | Housing Finish | Lumens | Color Temp | Watts | Voltage | Factory-Install Options | Features | |
|---|---|---|---|---|---|---|---|---|
SCXCF-D24UD-MCTP4  SPEC  IES INST | White | 4000LM Max. | 3000K/3500K/4000K/5000K | 20W/30W/40W | 120-277V AC 50/60Hz |
|  | |
SCXCF-D24UD-MCTP4-BK SPEC IES INST | Black | 4000LM Max. | 3000K/3500K/4000K/5000K | 20W/30W/40W | 120-277V AC 50/60Hz |
| | |
SCXCF-D36UD-MCTP4 SPEC IES INST | White | 8000LM Max. | 3000K/3500K/4000K/5000K | 60W/70W/80W | 120-277V AC 50/60Hz |
| | |
SCXCF-D36UD-MCTP4-BK SPEC IES INST | Black | 8000LM Max. | 3000K/3500K/4000K/5000K | 60W/70W/80W | 120-277V AC 50/60Hz |
| | |
SCXCF-D48UD-MCTP4 SPEC IES INST | White | 10000LM Max. | 3000K/3500K/4000K/5000K | 80W/90W/100W | 120-277V AC 50/60Hz |
| | |
SCXCF-D48UD-MCTP4-BK SPEC IES INST | Black | 10000LM Max. | 3000K/3500K/4000K/5000K | 80W/90W/100W | 120-277V AC 50/60Hz |
| |
