PC-1 120V Dusk-to-Dawn Photocell Light Switch
Technical Specs
- :: Dusk-to-dawn photocell light switch
- :: Input voltage 120V AC (100-120VAC), 50/60Hz
- :: Rated load 1800W tungsten / 1100VA ballast
- :: Power consumption 1.5VA
- :: On/Off levels 10~20 Lx On (dusk) / 30~60 Lx Off (dawn)
- :: Reaction time 30 seconds
- :: Detection angle 180°
- :: Stem size 1/2-inch NPT
- :: Wire length 6-inch, AWG #16
- :: Dimensions 76mm x 50mm x 37mm (3.0-inch x 2.0-inch x 1.5-inch)
- :: Operating temperature -40°F to 158°F
- :: IP54 rated
- :: UL Listed (E495588); conforms to UL 773A
Applications
- :: The Westgate PC-1 automatically switches lighting on at dusk and off at dawn, so outdoor fixtures run only when they are needed. Weatherproof and easy to install, it is built for all outdoor lights, including building exteriors, parking areas, walkways, signage, and security lighting. As the 120V model in the PC-1 lineup, it wires directly to standard 120V AC line-voltage circuits through its 1/2-inch NPT stem.
