SPEC SHEET
RD4TL-MCT5-BK Black 4-inch Round Trimless Recessed Downlight 20W 5CCT
Technical Specs
- :: Input: 120 VAC, 60 Hz
- :: Wattage: 20W
- :: Delivered Lumens: 1,600 lm
- :: Efficacy: 80 LM/W
- :: Dimming: TRIAC / ELV
- :: Power Factor: >0.9
- :: Total Harmonic Distortion: <25%
- :: Driver: Class 2 isolated low-voltage remote driver box included, with CCT selectable switch on driver box
- :: Wiring: FT4 rated cable with male/female quick connector; minimum 194-degree F supply conductors required
- :: CCT: 5CCT field selectable - 2700K / 3000K / 3500K / 4000K / 5000K
- :: CRI: 90
- :: Light Source: COB LED
- :: Optical: Deep regress optical design
- :: Lens: Polycarbonate
- :: Aperture: Round
- :: Housing: Die-cast aluminum heatsink
- :: Finish: Black
- :: Installation: Trimless mud-in, canless recessed; round mud-in plate; package includes fixture, trim, driver box, screws, and template
- :: Ceiling Cutout: 4-3/8-inch round
- :: Ceiling Thickness: 0.5-inch to 1-inch
- :: Mounting: IC rated for direct contact with insulation; wet location rated for covered ceiling mount only
Applications
- :: The Westgate RD4TL-MCT5-BK is the highest-output fixed round in a black finish, delivering 1,600 lumens from a 4-inch trimless aperture for larger rooms and higher ceilings. It anchors the round lineup above the 2-inch and 3-inch models where stronger illumination is needed. The black aperture suits dark-toned ceilings and low-glare accent applications.
